IKW08T120 Datasheet

  • IKW08T120

  • ?8A 1200V TO247 IGBT+Diode?

  • 15頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IKW08T120
^
TrenchStop Series
Low Loss DuoPack : IGBT in Trench and Fieldstop technology
with soft, fast recovery anti-parallel EmCon HE diode
C
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Approx. 1.0V reduced V
CE(sat)
and 0.5V reduced V
F
compared to BUP305D
Short circuit withstand time 鈥?10碌s
G
Designed for :
- Frequency Converters
- Uninterrupted Power Supply
Trench and Fieldstop technology for 1200 V applications offers :
- very tight parameter distribution
- high ruggedness, temperature stable behavior
NPT technology offers easy parallel switching capability due to
positive temperature coefficient in V
CE(sat)
Low EMI
Low Gate Charge
Very soft, fast recovery anti-parallel EmCon HE diode
Complete product spectrum and PSpice Models :
http://www.infineon.com/igbt/
V
CE
1200V
I
C
8A
V
CE(sat),Tj=25擄C
1.7V
T
j,max
150擄C
E
P-TO-247-3-1
(TO-247AC)
Type
IKW08T120
Package
TO-247AC
Ordering Code
Q67040-S4514
Maximum Ratings
Parameter
Collector-emitter voltage
DC collector current
T
C
= 25擄C
T
C
= 100擄C
Pulsed collector current,
t
p
limited by
T
jmax
Turn off safe operating area
V
CE
鈮?/div>
1200V,
T
j
鈮?/div>
150擄C
Diode forward current
T
C
= 25擄C
T
C
= 100擄C
Diode pulsed current,
t
p
limited by
T
jmax
Gate-emitter voltage
Short circuit withstand time
Power dissipation
T
C
= 25擄C
Operating junction temperature
Storage temperature
Soldering temperature, 1.6mm (0.063 in.) from case for 10s
T
j
T
stg
-
-40...+150
-55...+150
260
擄C
1)
Symbol
V
CE
I
C
Value
1200
16
8
Unit
V
A
I
Cpul s
-
I
F
24
24
16
8
I
Fpul s
V
GE
t
SC
P
tot
24
鹵20
10
70
V
碌s
W
V
GE
= 15V,
V
CC
鈮?/div>
1200V,
T
j
鈮?/div>
150擄C
1)
Allowed number of short circuits: <1000; time between short circuits: >1s.
1
Preliminary / Rev. 1 Jul-02
Power Semiconductors
