IHLP-5050FD-01 Datasheet

  • IHLP-5050FD-01

  • Low Profile, High Current Inductor

  • 4頁

  • VISHAY   VISHAY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IHLP-5050FD-01
Vishay Dale
Low Profile, High Current Inductor
FEATURES
鈥?/div>
Shielded construction.
鈥?/div>
Frequency range up to 5.0MHz.
鈥?/div>
Lowest DCR/碌H, in this package size.
鈥?Handles high transient current spikes without saturation.
鈥?Ultra low buzz noise, due to composite construction.
鈥?100% lead (Pb) free.
US PATENTED
6,204,744, several foreign patents,
and other patents pending
STANDARD ELECTRICAL SPECIFICATIONS
Lo
DCR m
鈩?/div>
DCR m
鈩?/div>
HEAT RATING SATURATION
INDUCTANCE TYPICAL MAX
CURRENT CURRENT
碌
H
鹵
20%
25
擄
C
25
擄
C
DC AMPS
3
DC AMPS
4
@100KHz, .25V, 0A
TYPICAL
TYPICAL
0.10
0.47
0.50
60
120
0.15
0.53
0.60
55
118
0.22
0.63
0.70
53
112
0.30
0.70
0.80
48
72
0.33
0.83
0.90
46
65
0.40
0.90
1.0
44
64
0.47
1.0
1.2
41
63
0.56
1.2
1.4
37
62
0.68
1.4
1.6
35
60
0.82
1.6
1.9
33
50
1.0
1.7
2.0
32
49
1.2
2.1
2.5
30
48
1.5
2.5
3.0
27
45
2.2
3.5
4.2
22
40
3.3
5.7
6.8
18
35
4.7
9.3
11.2
13.5
30
NOTES:
1. All test data is referenced to 25擄C ambient.
2. Operating Temperature Range - 55擄C to + 125擄C
3. DC current (A) that will cause an approximate
鈭員
of 40擄C.
4. DC current (A) that will cause Lo to drop approximately 20%
5. The part temperature (ambient + temp rise) should not exceed
125擄C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
APPLICATIONS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Notebook/Desktop/Server applications.
High current POL converters.
Low profile, high current power supplies.
Battery powered devices.
DC/DC converters in distributed power systems.
DC/DC converter for Field Programmable Gate Array (FPGA).
DIMENSIONS
in inches [millimeters]
Typical Pad Layout
0.542
[13.76]
0.195
[4.95]
0.310
[7.87]
0.508
[12.9]
Max.
0.520
鹵
0.02
[13.2
鹵
0.5]
0.256
[6.5] Max.
0.091
鹵
0.01
[2.3
鹵
0.3]
0.185
鹵
0.01
[4.7
鹵
0.3]
DESCRIPTION
IHLP-5050FD-01
MODEL
1.0
碌
H
INDUCTANCE VALUE
鹵
20%
INDUCTANCE
TOLERANCE
SAP PART NUMBERING GUIDELINES (INTERNAL)
I
H
L
P
5
0
5
SIZE
0
F
D
R
Z
1
R
0
M
TOL.
0
1
PRODUCT FAMILY
See the end of this data book for conversion tables
PACKAGE
CODE
INDUCTANCE
VALUE
SERIES
Document Number 34123
Revision 20-Jun-03
For technical questions, contact Magnetics@vishay.com
www.vishay.com
23
