IFE
International AC Front End
500 Watts
chassis mount versions
500 Watts
Meets EN55022-B
Meets EN61000-3-2 harmonic
current limits
Rugged coldplate construction
Product Overview
The International Front End (IFE) is an
enclosed chassis mount, AC Front End
which may be used with VIPAC Arrays,
MegaModules or any of Vicor's 300V
input DC-DC converters to create a
complete, low profile, high density,
AC-DC power supply.
The IFE operates from worldwide AC
mains and includes autoranging line
rectification, integral EMI filtering,
hold-up capacitors, harmonic current
attenuation and transient suppression. The
IFE incorporates Vicor's passive harmonic
current attenuation technology and FARM
modules to deliver 500 Watts while
meeting EN61000-3-2 limits. All internal
heat producing components are coupled to
the chassis for optimal thermal transfer.
Two rugged, coldplate packages are
available 鈥?one with threaded inserts and
the other with thru hole flanges 鈥?which
may be mounted directly to a cabinet wall
or an existing heat sink for high
temperature operation.
The International Front Ends (IFE)
provide an off-the-shelf solution for many
custom and standard power supply
requirements where space constraints and
time to market are critical.
Absolute Maximum Ratings
Parameter
L to N voltage
+Out to 鈥揙ut voltage
B OK to 鈥揙ut voltage
EN to 鈥揙ut voltage
Mounting torque
Operating temperature
Storage temperature
Rating
264
400
16
16
15 (1.7)
95
125
Unit
Vrms
Vdc
Vdc
Vdc
in-lbs (N-m)
擄C
擄C
6 M4 x 0.7
Chassis/BP
Ambient
Notes
Continuous
Part Numbering
IFE
Product
5
Type
5 = 500 W
C
0
Termination
0 = Connector
2
Product Grade
C = -20擄C to 95擄C (BP)
T = -40擄C to 95擄C (BP)
Base Style
1 = External flange
2 = Internal threaded
Options
Vicor Corp.
Tel: 800-735-6200, 978-470-2900 Fax: 978-475-6715
International Front End
Rev. 1.1
Page 1 of 7
