Plastic Fiber Optic IR LED
D
ESCRIPTION
IF-E91A-R
IF-E9A-R
The IF-E91A-R is the replacement for the now obsolete Motorola MFOE71
fiber optic LED in Industrial Fiber Optics鈥?family of devices. Each LED consists
of a
polycarbonate (PC)
housing, an internal active element such as an LED
subcomponent, and a cinch nut to hold the fiber in place. The PC housing
retains the active element and the cinch nut while optimizing coupling
between the active element and the jacketed 1000 碌m plastic fiber.
Working with this family of fiber optics is simple: No special tools or training
required. Only a sharp knife or razor blade is needed to terminate the plastic
fiber. When the fiber is inserted in the LED or detector housing, tighten the
cinch nut. Thereafter, the fiber can be removed simply by loosening the nut.
A
P P L I CAT I O N S
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
F
E AT U R E S
x
No Optical Design Required
x
Mates with Standard 1000 碌m Core Jacketed Plastic Fiber Cable
x
Internal Micro-Lens for Efficient Coupling
x
Inexpensive Plastic Connector Housing
x
Connector-Less Fiber Termination and Connection
x
Interference-Free Transmission from Light-Tight Housing
x
Excellent Linearity
Household Appliances
Motor Controller Triggering
PC-to-Peripheral Links
Medical Instruments
Automotive Electronics
Audio Systems
Electronic Games
Robotics Communications
M
A X I M U M
R
AT I N G S
(T
A
= 25擄C)
Operating and Storage
Temperature Range
(T
OP
, T
STG
) .....................-40擄 to 85擄C
Junction Temperature (T
J
) .............85擄C
Soldering Temperature
(2 mm from case bottom)
(T
S
) t
鈮?/div>
5 s .................................240擄C
Reverse Voltage (V
R
).........................3 V
Power Dissipation
(P
TOT
) TA = 25擄C ...................100 mW
De-rate Above 25擄C ..........1.33 mW/擄C
Forward Current, DC (I
F
) ...........30 mA
Surge Current (I
FSM
) t
鈮?/div>
10 碌sec......1 A
C
HA R A C T E R I S T I C S
(T
A
=25擄C)
Parameter
Peak Wavelength
Spectral Bandwidth (50% of I
MAX
)
Output Power Coupled into Plastic Fiber
(1 mm core diameter). Distance Lens to Fiber
鈮?.1
mm, 10 cm polished fiber, IF=20 mA
Switching Times (10% to 90% and
90% to 10%) (RL=47
鈩?
IF=10 mA)
Capacitance
Temperature Coefficient,
位
PEAK
Forward Voltage (IF=50 mA)
Symbol
位
PEAK
鈭單?/div>
桅
min
IF-E91A
950
40
>100
-10
1.0
25
1.5 max
0.3
Unit
nm
nm
碌W
dBm
碌s
pF
V
nm/K
tr, tf
C0
Vf
TC
位
Industrial Fiber Optics, Inc.
19
