Plastic Fiber Optic Phototransistor
D
ESCRIPTION
IF-D92
The IF-D92 is a high-sensitivity phototransistor detector housed in a 鈥渃onnector-
less鈥?style plastic fiber optic package. Optical response of the IF-D92 extends
from 400 to 1100 nm, making it compatible with a wide range of visible and
near-infrared LEDs and laser diode sources. This includes 650 nm visible red
LEDs used for optimum transmission in PMMA plastic optic fiber. The detector
package features an internal micro-lens and a precision-molded PBT housing to
ensure efficient optical coupling into standard 1000 碌m core plastic fiber cable.
A
P P L I C AT I O N
H
I G H L I G H T S
The IF-D92 is suitable for digital data links at rates up to 25 kbps. Analog band-
widths greater than 15 kHz are possible making the IF-D92 usable for high
frequency audio transmission. Phototransistor operation provides high internal
gain 鈥?reducing the amount of post amplification required in many circuits. The
integrated design of the IF-D92 makes it a simple, cost-effective solution in a
variety of analog and digital applications.
A
P P L I CAT I O N S
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
鉃?/div>
Low-Speed Digital Data Links
Motor Controller Triggering
Audio Links
Medical Instruments
Automotive Electronics
Robotics Communications
EMC/EMI Signal Isolation
Electronic Games
Process Control
F
E AT U R E S
x
High Optical Sensitivity
x
Mates with Standard 1000 um Core Jacketed Plastic Fiber Optic Cable
x
No Optical Design Required
x
Inexpensive but Rugged Plastic Connector Housing
x
Internal Micro-Lens for Efficient Optical Coupling
x
Connector-Less Fiber Termination
x
Light-Tight Housing provides Interference Free Transmission
M
A X I M U M
R
AT I N G S
(T
A
=25擄C)
Operating and Storage
Temperature Range
(T
OP
,T
STG
)......................-40擄 to 85擄C
Junction Temperature (T
J
) .............85擄C
Soldering Temperature
(2 mm from case bottom)
(T
S
) t
鈮?/div>
5s..................................240擄C
Collector Emitter Voltage (V
CEO
)....30 V
Emitter Collector Voltage (V
ECO
) .....5 V
Collector Current (I
C
)..................50 mA
Collector Peak Current
(ICM) t =1ms ..........................100 mA
Power Dissipation
(PTOT) TA =25擄C ...................100 mW
De-rate Above 25擄C ..........1.33 mW/擄C
C
HA R A C T E R I S T I C S
(T
A
=25擄C)
Parameter
Wavelength for Maximum Photosensitivity
Spectral Bandwidth (S=10% of S
MAX
)
Switching Times (10% to 90% and 90% to 10%)
(R
L
=1 k鈩? I
C
=1.0 mA, V
CE
=5 V,
位=950
nm)
Responsivity min. @ 880 nm
@ 632 nm
Collector Dark Current (V
CE
=15 volts)
Breakdown Voltage (I
C
=100 碌A(chǔ))
Breakdown Voltage (I
C
=100 碌A(chǔ))
Saturation Voltage (I
C
=250 碌A(chǔ), H=100 碌W)
Symbol
位
PEAK
鈭單?/div>
t r, tf
R
I
CEO
BV
CEO
BV
ECO
V
CE
sat
Min
鈥?/div>
400
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
30
5
鈥?/div>
Typ
870
鈥?/div>
20
100
50
鈥?/div>
鈥?/div>
鈥?/div>
0.15
Max
鈥?/div>
1100
鈥?/div>
鈥?/div>
鈥?/div>
100
鈥?/div>
鈥?/div>
鈥?/div>
Unit
nm
nm
碌s
碌A(chǔ)/碌W
碌A(chǔ)/碌W
nA
V
V
V
