鈭?/div>
Enhanced N channel FET with no inherent diode to Vcc
Undershoot clamp diodes on all switch and control inputs
Active low and high enable control
25鈩?resistors for low noise
Available in SOIC and QSOP packages
IDTQS32862
DESCRIPTION:
The QS32862 provides a set of ten high speed CMOS, TTL Compatible
bus switches. The switches are controlled by independent active Low
enable (BE) and High enable (BE) controls.
The QS32862 includes internal 25鈩?series termination resistors to
reduce reflection noise in high speed applications. When closed, the switch
acts as the source (series) termination for the driver connected to it. The
QS32862 is ideal for switching digital buses as well as hot-plugging, hot-
docking, and voltage translation.
The QS32862 is characterized for operation at -40擄C to +85擄C.
APPLICATIONS
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
Hot-swapping, hot-docking
Voltage translation (5V to 3.3V)
Power conservation
Capacitance reduction and isolation
Applications requiring Active-High enabling
Clock gating
Bus isolation
FUNCTIONAL BLOCK DIAGRAM
A
0
B
0
A
9
B
9
BE
BE
INDUSTRIAL TEMPERATURE RANGE
1
c
1999
Integrated Device Technology, Inc.
FEBRUARY 2000
DSC-5723/-
