IDT7MB4048S30P Datasheet

  • IDT7MB4048S30P

  • 512K x 8 CMOS STATIC RAM MODULE

  • 6頁

  • IDT

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

512K x 8
CMOS STATIC RAM MODULE
Integrated Device Technology, Inc.
IDT7MB4048
FEATURES:
鈥?High-density 4-megabit (512K x 8) Static RAM module
鈥?Fast access time: 25ns (max.)
Surface mounted plastic packages on a 32-pin, 600 mil
FR-4 DIP substrate
鈥?Single 5V (鹵10%) power supply
鈥?Inputs/outputs directly TTL-compatible
DESCRIPTION:
The IDT7MB4048 is a 4-megabit (512K x 8) Static RAM
module constructed on a multilayer epoxy laminate (FR-4)
substrate using four 1 megabit SRAMs and a decoder. The
IDT7MB4048 is available with access times as fast as 25ns.
The IDT7MB4048 is packaged in a 32-pin FR-4 DIP resulting
in the JEDEC footprint in a package 1.6 inches long and 0.6
inches wide.
All inputs and outputs of the IDT7MB4048 are TTL-com-
patible and operate from a single 5V supply. Fully asynchro-
nous circuitry requires no clocks or refresh for operation and
provides equal access and cycle times for ease of use.
PIN CONFIGURATION
A
18
A
16
A
14
A
12
A
7
A
6
A
5
A
4
A
3
A
2
A
1
A
0
I/O
0
I/O
1
I/O
2
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
FUNCTIONAL BLOCK DIAGRAM
Vcc
A
15
A
17
A
13
A
8
A
9
A
11
A
10
ADDRESS
19
512K x 8
RAM
WE
OE
CS
WE
OE
CS
8
I/O
2675 drw 02
I/O
7
I/O
6
I/O
5
I/O
4
I/O
3
2675 drw 01
DIP
TOP VIEW
PIN NAMES
I/O
0-7
A
0-18
Data Inputs/Outputs
Addresses
Chip Select
Write Enable
Output Enable
Power
Ground
2675 tbl 01
CS
WE
OE
V
CC
GND
The IDT logo is a registered trademark of Integrated Device Technology Inc.
COMMERCIAL TEMPERATURE RANGE
漏1996 Integrated Device Technology, Inc.
DECEMBER 1995
DSC-2675/6
7.11
1
