IDT74CBTLV3244Q Datasheet

  • IDT74CBTLV3244Q

  • BUS SWITCH|CMOS|SSOP|20PIN|PLASTIC

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IDT74CBTLV3244
LOW-VOLTAGE OCTAL BUS SWITCH
INDUSTRIAL TEMPERATURE RANGE
LOW-VOLTAGE OCTAL
BUS SWITCH
IDT74CBTLV3244
FEATURES:
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Pin-out compatible with standard '244 logic
5鈩?A/B bidirectional switch
Isolation Under Power-Off Conditions
Over-voltage tolerant
Latch-up performance exceeds 100mA
V
CC
= 2.3V - 3.6V, Normal Range
ESD > 2000V per MIL-STD-883, Method 3015;
> 200V using machine model (C = 200pF, R = 0)
Available in SSOP, QSOP, and TSSOP packages
DESCRIPTION:
The octal bus switch has standard 244 pinouts. The CBTLV3244 is
designed for asynchronous communication between data buses. Sets of
four switches are controlled by one output Enable (OE). When
OE
is low,
the set of four bus switches is on and port A is connected to port B. When
OE
is high, the set of four bus switches is off and a high impedance exists
between port A and port B.
To ensure the high-impedance state during power up or power down,
both
OEs
should be tied to V
CC
through a pullup resistor.
APPLICATIONS:
鈥?3.3V High Speed Bus Switching and Bus Isolation
FUNCTIONAL BLOCK DIAGRAM
2
1A1
SW
18
1B1
SIMPLIFIED SCHEMATIC, EACH
SWITCH
8
1A4
SW
12
1B4
A
B
1
1OE
OE
11
2A1
SW
9
2B1
17
2A4
SW
3
2B4
19
2OE
The IDT logo is a registered trademark of Integrated Device Technology, Inc.
INDUSTRIAL TEMPERATURE RANGE
1
c
2001
Integrated Device Technology, Inc.
SEPTEMBER 2001
DSC-5393/2
