IDT74ALVCH16374
3.3V CMOS 16-BIT EDGE-TRIGGERED D-TYPE LATCH WITH 3-STATE OUTPUTS
INDUSTRIAL TEMPERATURE RANGE
3.3V CMOS 16-BIT EDGE-
TRIGGERED D-TYPE
LATCH WITH 3-STATE
OUTPUTS AND BUS-HOLD
鈥?0.5 MICRON CMOS Technology
鈥?Typical t
SK(o)
(Output Skew) < 250ps
鈥?ESD > 2000V per MIL-STD-883, Method 3015; > 200V using
machine model (C = 200pF, R = 0)
鈥?V
CC
= 3.3V 鹵 0.3V, Normal Range
鈥?V
CC
= 2.7V to 3.6V, Extended Range
鈥?V
CC
= 2.5V 鹵 0.2V
鈥?CMOS power levels (0.4碌 W typ. static)
碌
鈥?Rail-to-Rail output swing for increased noise margin
鈥?Available in SSOP, TSSOP, and TVSOP packages
IDT74ALVCH16374
FEATURES:
DESCRIPTION:
DRIVE FEATURES:
鈥?High Output Drivers: 鹵24mA
鈥?Suitable for heavy loads
APPLICATIONS:
鈥?3.3V high speed systems
鈥?3.3V and lower voltage computing systems
This 16-bit edge-triggered D-type flip-flop is built using advanced dual metal
CMOS technology. The ALVCH16374 is particularly suitable for implementing
buffer registers, I/O ports, bidirectional bus drivers, and working registers. It can
be used as two 8-bit flip-flops or one 16-bit flip-flop. On the positive transition of
the clock (CLK) input, the Q outputs of the flip-flop take on the logic levels at the
data (D) inputs.
OE
can be used to place the eight outputs in either a normal logic
state (high or low logic levels) or a high-impedance state. In the high-impedance
state, the outputs neither load nor drive the bus lines significantly. The high-
impedance state and the increased drive provide the capability to drive bus lines
without need for interface or pullup components.
OE
does not affect internal
operations of the flip-flop. Old data can be retained or new data can be entered
while the outputs are in the high-impedance state.
The ALVCH16374 has been designed with a 鹵24mA output driver. This
driver is capable of driving a moderate to heavy load while maintaining speed
performance.
The ALVCH16374 has 鈥渂us-hold鈥?which retains the inputs鈥?last state
whenever the input goes to a high impedance. This prevents floating inputs and
eliminates the need for pull-up/down resistor.
FUNCTIONAL BLOCK DIAGRAM
1
OE
1
2
OE
24
1
C LK
48
2
CLK
25
C1
2
C1
1
Q
1
2
D
1
36
13
2
Q
1
1
D
1
47
1D
1D
TO 7 OTHER C HANN ELS
TO 7 OTHER CH ANNELS
The IDT logo is a registered trademark of Integrated Device Technology, Inc.
INDUSTRIAL TEMPERATURE RANGE
1
漏 1999 Integrated Device Technology, Inc.
APRIL 1999
DSC-4564/1
