Port B bus sizing of 36 bits (long word), 18 bits (word) and 9 bits
(byte)
Big- or Little-Endian format for word and byte bus sizes
Master Reset clears data and configures FIFO, Partial Reset
clears data but retains configuration settings
Mailbox bypass registers for each FIFO
Free-running CLKA and CLKB may be asynchronous or coincident
(simultaneous reading and writing of data on a single clock edge
is permitted)
Auto power down minimizes power dissipation
Available in space saving 128-pin Thin Quad Flatpack (TQFP)
Pin compatible to the lower density parts, IDT72V3624/72V3634/
72V3644/72V3654/72V3664/72V3674
擄
擄
Industrial temperature range (鈥?0擄C to +85擄C) is available
FUNCTIONAL BLOCK DIAGRAM
MBF1
Mail 1
Register
Output Bus-
Matching
Input
Register
36
RAM ARRAY
16,384 x 36
32,768 x 36
65,536 x 36
36
Output
Register
CLKA
CSA
W/RA
ENA
MBA
MRS1
PRS1
Port-A
Control
Logic
36
FIFO1,
Mail1
Reset
Logic
36
Write
Pointer
Read
Pointer
Status Flag
Logic
EFB/ORB
AEB
FFA/IRA
AFA
FS2
FS0/SD
FS1/SEN
A
0
-A
35
EFA/ORA
AEA
FIFO1
Programmable Flag
Offset Registers
16
FIFO2
Timing
Mode
FWFT
B
0
-B
35
Status Flag
Logic
Read
Pointer
Write
Pointer
36
FFB/IRB
AFB
36
RT1
RTM
RT2
Output
Register
Input Bus-
Matching
36
16,384 x 36
32,768 x 36
65,536 x 36
Mail 2
Register
36
Input
Register
FIFO1 and
FIFO2
Retransmit
Logic
RAM ARRAY
FIFO2,
Mail2
Reset
Logic
MRS2
PRS2
Port-B
Control
Logic
4677 drw01
MBF2
