3 pairs of programmable skew outputs
Low skew: 200ps same pair, 250ps all outputs
Selectable positive or negative edge synchronization:
Excellent for DSP applications
Synchronous output enable
Output frequency: 3.75MHz to 100MHz
2x, 4x, 1/2, and 1/4 outputs
5V with TTL outputs
3 skew grades:
IDT5993A-2: t
SKEW0
<250ps
IDT5993A-5: t
SKEW0
<500ps
IDT5993A-7: t
SKEW0
<750ps
3-level inputs for skew and PLL range control
PLL bypass for DC testing
External feedback, internal loop filter
46mA I
OL
high drive outputs
Low Jitter: <200ps peak-to-peak
Outputs drive 50鈩?terminated lines
Available in QSOP Package
IDT5993A
DESCRIPTION:
The IDT5993A is a high fanout PLL based clock driver intended for
high performance computing and data-communications applications. A
key feature of the programmable skew is the ability of outputs to lead or
lag the REF input signal. The IDT5993A has six programmable skew
outputs and two zero skew outputs. Skew is controlled by 3-level input
signals that may be hard-wired to appropriate HIGH-MID-LOW levels.
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
FUNCTIONAL BLOCK DIAGRAM
G ND/sOE
Skew
Select
3
3
1F1:0
V
CCQ
/PE
Skew
Select
REF
PLL
FB
3
FS
Skew
Select
3
3
3F1:0
3
3
2F1:0
1Q
0
1Q
1
2Q
0
2Q
1
3Q
0
3Q
1
4Q
0
4Q
1
COMMERCIAL AND INDUSTRIAL TEMPERATURE RANGES
1
c
1999 Integrated Device Technology, Inc.
AUGUST 2000
DSC - 5844
