ICP-2010 Exportable
Voice Grade Channel
Processor
Features
q
q
Description
The ICP-2010 is
processor. With
can be used as
additional DSP
simultaneously.
M/A-COM鈥檚 newest exportable Voice Grade Channel
an altogether new DSP board design, the ICP-2010
a single channel processor or con鏗乬ured with one
(ICP-2110) to process two voice grade channels
OOK, FSK, VFT, PSK, QAM Modems
Complete Fax processing, including Group
3 and V.17
R.101A/B, 2400/1200 bps Strapping
Async, Bisync, HDLC, SDLC, X.25, SNA,
DDCMP, IPARS Protocols
ASCII-7, ASCII-8, EBCDIC, Baudot Coding
Analog and PCM E1/T1 Inputs
PC-based Control Software (standard)
q
q
q
q
q
The ICP-2010 performs demodulation, demultiplexing, bit stream
synchronization and back-end processing for most commercially
available modem and voice frequency telegraphy (VFT) signals, as
well as complete Group 3 and V.17 FAX signals. In addition, the ICP-
2010 can generate the modem and VFT signals that it is designed to
process.
Two analog inputs are available on the ICP-2010, and M/A-COM鈥檚
Dual Mode E1/T1 daughter card is used to provide PCM Level 1 input
to the ICP-2010.
The ICP-2010 comes standard with M/A-COM鈥檚 Control Monitor
Software for PC-based applications.
All of these new features represent the next generation in Voice
Grade Channel Processing from M/A-COM鈥檚 Communication
Technologies Center.
