IBM04184AQLAD-5P Datasheet

  • IBM04184AQLAD-5P

  • x18 Fast Synchronous SRAM

  • 24頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

.
Preliminary
Features
鈥?128K x 36 or 256K x 18 Organizations
鈥?/div>
CMOS Technology
IBM04184AQLAD
IBM04364AQLAD
128K x 36 & 256K x 18 SRAM
鈥?Common I/O
鈥?Asynchronous Output Enable and Power Down
Inputs
鈥?Boundary Scan using limited set of JTAG 1149.1
functions
鈥?Byte Write Capability & Global Write Enable
鈥?7 x 17 Bump Ball Grid Array Package with
SRAM JEDEC Standard Pinout and Boundary
SCAN Order
鈥?Programmable Impedance Output Drivers
鈥?Synchronous Register Latch Mode Of Operation
with Self-Timed Late Write
鈥?Single Differential Input and Output Clock
鈥?+3.3V Power Supply, 1.9V V
DDQ
, V
REF
&
Ground
鈥?Pseudo HSTL Input and Output levels
鈥?Registered Addresses, Write Enables, Sync
Select and Data Ins
Description
The IBM04184AQLAD and IBM04364AQLAD 4Mb
SRAM
S
are Synchronous Register Latch Mode, high
performance CMOS Static Random Access Memo-
ries that are versatile, wide I/O, and achieve 5.0ns
access and cycle times. Dual differential K clocks
are used to initiate the read/write operation, and all
internal operations are self-timed. At the rising edge
of the K Clock, all Addresses, Write-Enables, Sync
Select, and Data Ins are registered internally. An
internal write buffer allows write data to follow one
cycle after addresses and controls. The chip is oper-
ated with a +3.3V core power supply, has a 1.9V or
1.5V output power supply, and is compatible with
HSTL I/O interfaces and 1.5V I/O levels as well.
03K4297.E35614
Revised 2/99
漏IBM Corporation. All rights reserved.
Use is further subject to the provisions at the end of this document.
Page 1 of 24
