QUAD Series
Input I/O Modules
鈥?UL, CSA, and CE
Solid state I/O switching modules deliv-
er an electrically clean, photo-isolated,
noise-free "output" interface from
logic level control systems to external
loads such as motors, valves, solenoids,
etc. -- or an "input" interface from the
load or sensors to microprocessor or
computer-based logic level systems.
Designed for long, reliable service in
demanding industrial environments.
INPUT SPECIFICATIONS
Nominal Input Voltage
Min. Input Voltage
Max. Input Voltage
Max. Input Current @ Max. Input Voltage
Drop Out Current
Allowable Off-State Input Current
Allowable Off-State Voltage
Input Resistance
IAC5Q
120 Vrms/Vdc
90 Vrms/Vdc
140 Vrms/Vdc
10 mArms
2.5 mArms
3.0 mArms
50 Vrms/Vdc
鈥?/div>
IAC5AQ
240Vrms/Vdc
180 Vrms/Vdc
280 Vrms/Vdc
8 mArms
1.5 mArms
2.0 mArms
120 Vrms/Vdc
鈥?/div>
IDC5Q
24 Vrms, 48 Vdc
10 Vrms/Vdc
60 Vrms/Vdc
30 mArms
1.0 mArms
1.0 mArms
2 Vrms/Vdc
鈥?/div>
IDC5BQ
24 Vdc
3.3 Vdc
32 Vdc
32 mAdc
1.0 mAdc
1.0 mAdc
2 Vdc
1 k鈩?/div>
OUTPUT SPECIFICATIONS
Nominal Logic Supply Voltage
Min. Logic Voltage
Max. Logic Voltage
Typical Logic Supply Current @ Nominal Voltage
Max. Logic Supply Current @ Max. Logic Voltage
Max. Logic Supply Leakage Current @ Max. Logic Voltage
Max. Output Voltage
Max. Output Current
Max. Output Leakage Current
Max. Output Voltage Drop @ Max. Output Current
Max. Turn-On Time @ Max. Input Voltage
Max. Turn-Off Time
5.0 Vdc
4.5 Vdc
6.0 Vdc
10 mAdc
14.5 mAdc
20 碌A(chǔ)dc
30 Vdc
50 mAdc
20 碌A(chǔ)dc
200 mVdc
20 ms
30 ms
5.0 Vdc
4.5 Vdc
6.0 Vdc
10 mAdc
14.5 mAdc
20 碌A(chǔ)dc
30 Vdc
50 mAdc
20 碌A(chǔ)dc
200 mVdc
20 ms
30 ms
5.0 Vdc
4.5 Vdc
6.0 Vdc
10 mAdc
14.5 mAdc
20 碌A(chǔ)dc
30 Vdc
50 mAdc
20 碌A(chǔ)dc
200 mVdc
1.0 ms
1.0 ms
5.0 Vdc
4.5 Vdc
6.0 Vdc
10 mAdc
14.5 mAdc
20 碌A(chǔ)dc
30 Vdc
50 mAdc
20 碌A(chǔ)dc
200 mVdc
30 碌s
60 碌s
漏1998 CRYDOM CORP Specifications subject to change without notice.
FastFax Document No. 307
SERIES QINPUT.070898, PAGE 1 OF 2
