IA82050-PLC28I-01 Datasheet

  • IA82050-PLC28I-01

  • ASYNCHRONOUS SERIAL CONTROLLER

  • 11頁

  • INNOVASIC   INNOVASIC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IA82050
ASYNCHRONOUS SERIAL CONTROLLER
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Data Sheet
As of Production Ver. 01
Form, Fit, and Function Compatible with the Intel
廬
82050 and 82510
Packaging options available: 28 Pin Plastic DIP and 28 Lead Plastic Leaded
Chip Carrier
Asynchronous Serial Channel Operation
Separate Transmit and Receive FIFOs with Programmable Threshold
Programmable Baud Rate Generators up to 288K Baud
Special Protocol Features
- Control Character Recognition
- Auto Echo and Loopback Modes
- 9-Bit Protocol Support
- 5 to 9 Bit Character Format
The IA82050 is a "plug-and-play" drop-in replacement for the original IC. innovASIC produces replacement ICs
using its MILES
TM
, or Managed IC Lifetime Extension System, cloning technology. This technology produces
replacement ICs far more complex than "emulation" while ensuring they are compatible with the original IC.
MILES
TM
captures the design of a clone so it can be produced even as silicon technology advances. MILES
TM
also verifies the clone against the original IC so that even the "undocumented features" are duplicated. This data
sheet documents all necessary engineering information about the IA82050 including functional and I/O
descriptions, electrical characteristics, and applicable timing.
IA82050 Package Pinout
IA82050
D4
D5
D6
D7
INT
TXD
VSS
X2 or OUT2n
X1 or CLK
SCLK or RIn
DSRn or TA or OUT0n
DCDn or ICLK or OUT1n
RXD
CTSn
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(28)
D3
D2
D1
D0
A2
A1
A0
VDD
RDn
WRn
CSn
RESET
RTSn
DTRn or TB
DCDn or ICLK or OUT1n
RESET
CTSn
RTSn
RXD
CSn
INT
TXD
VSS
X2 or OUT2n
X1 or CLK
SCLK or RIn
DSRn or TA or OUT0n
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12) (13) (14) (15) (16) (17) (18)
(25)
(24)
D0
A2
A1
A0
VDD
RDn
WRn
(4) (3) (2) (1) (28) (27) (26)
D7 D6 D5 D4 D3 D2 D1
28 Pin DIP
(27)
(26)
(25)
(24)
(23)
(22)
(21)
(20)
(19)
(18)
(17)
(16)
(15)
IA82050
28 Pin LCC
(23)
(22)
(21)
(20)
(19)
Copyright
漏
2001
ENG211010326-00
The End of Obsolescence鈩?/div>
DTRn or TB
innovASIC
錚?/div>
www.innovasic.com
Customer Support:
1-888-824-4184
Page 1 of 11
