IA3008-MB30A
Contact image sensor heads
Monochrome image sensor heads
for multi-function
IA3008-MB30A
Using our highly efficient White Frame, ROHM鈥檚 monochrome image sensor heads achieve even faster scanning times.
300 dpi compact monochrome image sensor head is available for high speed application such as laser printers.
!
Applications
Image input device for multiple function facsimiles such as scanner and multiple function printer.
!
Features
1) Signal amplifier built in to the image sensor IC in order to increase immunity to external noise.
2) The LED light source is mounted on the same substrate as the sensor chip which makes it possible to package the
device with lighter weight and an extremely small size.
3) 5 volts single power supply is needed for the CIS which will simplify the power supply requirement.
4) The ceramic substrate is used for excellent dimensional accuracy and thermal stability.
5) Using a special highly reflective frame that is achieved high speed scanning.
!
External dimensions
(Unit : mm)
232
+
0.5
鈭?/div>
218.8(Effective Read Width : 207.4)
14.05
+
0.5
鈭?/div>
9.95
+
0.5
鈭?/div>
No.1 Pixel
11.18 4鈭捨?.9 Effective Depth6
1.8
19.05
+
0.3
鈭?/div>
5.7
11.38
11.38
+
0.2
鈭?/div>
A
(25)
No.7
No.1
PIN No.
SIGNAL
A
O
GND
V
DD
SI
CLK
PIN No.
No.6
No.7
Max.2
(13.8)
(10.4)
(1.41)
SIGNAL
G
LED
V
LED
Deflection of glass surface : WIth the A-direction positive ,
0鈭?.22 with respect to the cover glass.
Connector
:
IL-Z-7P-CLIP(JAE)
Socket Housing
:
IL-Z-7S-125C3(JAE)
Socket Contact
:
IL-Z-C3-15000(JAE)
No.1
No.2
No.3
No.4
No.5
15
19.05
1/4
