HYS64D128020GBDL-7-A Datasheet

  • HYS64D128020GBDL-7-A

  • ?1GB (1024Mx64) PC2100 2-bank?

  • 11頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HYS64D128020GBDL-[6/7]-A
DDR-SDRAM SO-DIMM Modules
2.5V 200Pin DDR-I SDRAM Small Outline Modules
1GB Module
PC1600, PC2100 & PC2700
Preliminary Data Sheet V0.6, 2003-01-07
鈥?200-pin Unbuffered 8-Byte Dual-In-Line
DDR-I SDRAM non-parity Small Outline
Modules
鈥?128M x 64 organization with two memory
banks
鈥?JEDEC standard Double Data Rate
Synchronous DRAMs (DDR-I SDRAM)
鈥?Single +2.5V (
鹵
0.2V) power supply
鈥?Uses eight 1Gbit DDR-I SDRAM components
(2x 64Mb x8) made of stacked 512Mb dies in
P-TFBGA package.
鈥?Programmable CAS Latency, Burst Length,
and Wrap Sequence (Sequential &
Interleave)
鈥?Auto Refresh (CBR) and Self Refresh
鈥?All inputs and outputs SSTL_2 compatible
鈥?Serial Presence Detect with E
2
PROM
鈥?Jedec standard form factor:
67.60mm
麓
31.75mm
麓
3.80mm
鈥?Gold plated contacts
Performance
-6
Component Speed Grade
Module Speed Grade
f
CK
f
CK
-7
DDR266A
PC2100
143
133
Unit
DDR333
PC2700
166
133
Clock Frequency (max.) @ CL = 2.5
Clock Frequency (max.) @ CL = 2
MHz
MHz
The HYS64D128020GBDL are industry standard 200-pin 8-byte Small Outline Dual in-line Memory
Modules (DIMMs) organized as 128M x 64 in two memory banks. The memory array is designed
with Double Data Rate Synchronous DRAMs. A variety of decoupling capacitors are mounted on
the PC board. The DIMMs feature serial presence detect based on a serial E
2
PROM device using
the 2-pin I
2
C protocol. The first 128 bytes are programmed with configuration data and the second
128 bytes are available to the customer.
INFINEON Technologies AG
1
V0.6, 2003-01-07
