HYMR16416 Datasheet

  • HYMR16416

  • 32Mx16|2.5V|40|-|Direct RDRAM - 64MB RIMM

  • 17頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Direct Rambus RIMM
鈩?/div>
with 128/144Mbit RDRAMs
Preliminary
Overview
The Rambus
廬
RIMM
TM
module is a general purpose high-
performance memory subsystem suitable for use in a broad
range of applications including computer memory, personal
computers, workstations, and other applications where high
bandwidth and low latency are required.
The Rambus RIMM module consist of 128Mb/144Mb
Direct Rambus DRAM devices. These are extremely high-
speed CMOS DRAMs organized as 8M words by 16 or 18
bits. The use of Rambus Signaling Level (RSL) technology
permits 600MHz ,711MHz or 800MHz transfer rates while
using conventional system and board design technologies.
Direct RDRAM devices are capable of sustained data
transfers at 1.25 ns per two bytes (10ns per 16 bytes).
The RDRAM architecture enables the highest sustained
bandwidth for multiple, simultaneous randomly addressed
memory transactions. The separate control and data buses
with independent row and column control yield over 95%
bus efficiency. The Direct RDRAM's 16-banks architecture
supports up to four simultaneous transactions per device.
Key Timing Parameters/Part Numbers
The following table lists the frequency and latency bins
available from RIMM modules. An optional -LP designator
is used to indicate low power modules.
Table 1: RIMM Module Frequency and Latency
Organization
x16
x16
x16
x16
x18
x18
x18
x18
I/O Freq.
MHz
600
711
800
800
600
711
800
800
t rac (Row Access
Time) ns
53
45
45
40
53
45
45
40
Features
w
High speed 800,711 and 600 MHz RDRAM storage
w
184 edge connector pads with 1 mm pad spacing
w
Maximum module PCB size: 133.5mm x 31.75mm x
1.37mm(5.21鈥?x 1.25鈥?x 0.05鈥?
w
Each RDRAM has 32 banks, for a total of 512, 384, 256,
192 or 128 banks on each 256MB, 192MB, 128MB,
96MB, or 64MB module respectively
w
Gold plated edge connector pad contacts
wSerial
Presence Detect(SPD) support
戮
w
Operates from a 2.5 volt supply (
隆
5%)
w
Low power and powerdown self refresh modes
w
Separate Row and Column buses for higher
efficiency
Form Factor
The Rambus RIMM modules are offered in a 184-pad 1mm
edge connector pad pitch from factor suitable for either 184
or 168 contact RIMM connectors. The RIMM module is
suitable for desktop and other system applications. Figure 1
shows an eight device Rambus RIMM module without heat
spreader.
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume any
responsibility for use of circuits described. No patent licenses are implied.
Rev. 1.0/Dec.99
1
