HYMD216726AL6 Datasheet

  • HYMD216726AL6

  • 16Mx72|2.5V|M/K/H/L|x5|DDR SDRAM - Unbuffered DIMM 128MB

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

16Mx72 bits
Unbuffered DDR SO-DIMM
HYMD216726A(L)6-M/K/H/L
DESCRIPTION
Hynix HYMD216726A(L)6-M/K/H/L series is unbuffered 184-pin double data rate Synchronous DRAM Dual In-Line
Memory Modules (DIMMs) which are organized as 16Mx72 high-speed memory arrays. Hynix HYMD216726A(L)6-M/K/
H/L series consists of eighteen 16Mx16 DDR SDRAM in 400mil TSOP II packages on a 184pin glass-epoxy substrate.
Hynix HYMD216726A(L)6-M/K/H/L series provide a high performance 8-byte interface in 5.25" width form factor of
industry standard. It is suitable for easy interchange and addition.
Hynix HYMD216726A(L)6-M/K/H/L series is designed for high speed of up to 133MHz and offers fully synchronous
operations referenced to both rising and falling edges of differential clock inputs. While all addresses and control
inputs are latched on the rising edges of the clock, Data, Data strobes and Write data masks inputs are sampled on
both rising and falling edges of it. The data paths are internally pipelined and 2-bit prefetched to achieve very high
bandwidth. All input and output voltage levels are compatible with SSTL_2. High speed frequencies, programmable
latencies and burst lengths allow variety of device operation in high performance memory system.
Hynix HYMD216726A(L)6-M/K/H/L series incorporates SPD(serial presence detect). Serial presence detect function is
implemented via a serial 2,048-bit EEPROM. The first 128 bytes of serial PD data are programmed by Hynix to identify
DIMM type, capacity and other the information of DIMM and the last 128 bytes are available to the customer.
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
128MB (16M x72) Unbuffered DDR DIMM based on
16Mx16 DDR SDRAM
JEDEC Standard 184-pin dual in-line memory module
(DIMM)
Error Check Correction (ECC) Capability
2.5V +/- 0.2V VDD and VDDQ Power supply
All inputs and outputs are compatible with SSTL_2
interface
Fully differential clock operations (CK & /CK) with
100MHz/125MHz/133MHz
All addresses and control inputs except Data, Data
strobes and Data masks latched on the rising edges
of the clock
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Data(DQ), Data strobes and Write masks latched on
both rising and falling edges of the clock
Data inputs on DQS centers when write (centered
DQ)
Data strobes synchronized with output data for read
and input data for write
Programmable CAS Latency 2 / 2.5 supported
Programmable Burst Length 2 / 4 / 8 with both
sequential and interleave mode
tRAS Lock-out function supported
Internal four bank operations with single pulsed RAS
Auto refresh and self refresh supported
8192refresh cycles / 64ms
ORDERING INFORMATION
Part No.
HYMD216726A(L)6-M
HYMD216726A(L)6-K
HYMD216726A(L)6-H
HYMD216726A(L)6-L
V
DD
=2.5V
V
DDQ
=2.5V
Power Supply
Clock Frequency
133MHz (*DDR266:2-2-2)
133MHz(*DDR266A)
133MHz(*DDR266B)
100MHz(*DDR200)
Interface
Form Pactor
SSTL_2
184pin Unbuffered DIMM
5.25 x 1.25 x 0.15 inch
* JEDEC Defined Specifications compliant
This document is a general product description and is subject to change without notice. Hynix Semiconductor does not assume any
responsibility for use of circuits described. No patent licenses are implied.
Rev. 0.2/May. 02
1
