based on 1Mx16 SDRAM with LVTTL, 2 banks & 4K Refresh
HYM4V33100DTYG Series
DESCRIPTION
The Hynix HYM4V33100DTYG Series are 1Mx16bits Synchronous DRAM Modules. The modules are composed of two 1Mx16bits
CMOS Synchronous DRAMs in 400mil 50pin TSOP-II package, on a 132pin glass-epoxy printed circuit board. Two 0.22uF and one
0.1uF decoupling capacitors per each SDRAM are mounted on the PCB.
The Hyundai HYM4V33100DTYG Series are AGP In-line Memory Modules suitable for easy interchange and addition of 4Mbytes
memory. The Hyundai HYM4V33100DTYG Series are fully synchronous operation referenced to the positive edge of the clock . All
inputs and outputs are synchronized with the rising edge of the clock input. The data paths are internally pipelined to achieve very high
bandwidth.
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
PC133/PC100MHz support
132pin SDRAM AIMM
1.4鈥?(35.56mm) Height PCB with double sided com-
ponents
Single 3.3鹵0.3V power supply
- 1, 2, 4 or 8 or Full page for Sequential Burst
鈥?/div>
鈥?/div>
鈥?/div>
All device pins are compatible with LVTTL interface
- 1, 2, 4 or 8 for Interleave Burst
Data mask function by DQM
鈥?/div>
SDRAM internal banks : two banks
Programmable CAS Latency ; 2, 3 Clocks
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Module bank : one physical bank
Auto refresh and self refresh
4096 refresh cycles / 64ms
Programmable Burst Length and Burst Type
ORDERING INFORMATION
Part No.
HYM4V33100DTYG-75
Clock
Frequency
133MHz
Internal
Bank
4 Banks
Ref.
4K
Power
Normal
SDRAM
Package
TSOP-II
Plating
Gold
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume any responsibility for use of
circuits described. No patent licenses are implied.
