HYM4V33100BTWG-75 Datasheet

  • HYM4V33100BTWG-75

  • x32 SDRAM Module

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

1Mx32 bits
PC133 SDRAM AIMM
based on 1Mx32 SDRAM with LVTTL, 2 banks & 4K Refresh
HYM4V33100BTWG Series
DESCRIPTION
The Hynix HYM4V33100BTWG
Series are 1Mx32bits Synchronous DRAM Modules. The modules are composed of one 1Mx32bits
CMOS Synchronous DRAMs in 400mil 86pin TSOP-II package, on a 132pin glass-epoxy printed circuit board. Two 0.22uF and one
0.1uF decoupling capacitors per each SDRAM are mounted on the PCB.
The Hyundai HYM4V33100BTWG
Series are AGP In-line Memory Modules suitable for easy interchange and addition of 4Mbytes
Series are fully synchronous operation referenced to the positive edge of the clock . All
memory. The Hyundai HYM4V33100BTWG
bandwidth.
inputs and outputs are synchronized with the rising edge of the clock input. The data paths are internally pipelined to achieve very high
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
PC133/PC100MHz support
132pin SDRAM
AIMM
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Single 3.3
鹵
0.3V power supply
- 1, 2, 4 or 8 or Full page for Sequential Burst
All device pins are compatible with LVTTL interface
- 1, 2, 4 or 8 for Interleave Burst
Data mask function by DQM
鈥?/div>
SDRAM internal banks : two banks
Programmable CAS Latency ; 2, 3 Clocks
Module bank : one physical bank
Auto refresh and self refresh
4096 refresh cycles / 64ms
Programmable Burst Length and Burst Type
1.4鈥?(35.56mm) Height PCB with double sided com-
ponents
ORDERING INFORMATION
Clock
Frequency
133MHz
Part No.
HYM4V33100BTWG-75
Internal
Bank
2 Banks
Ref.
4K
Power
Normal
SDRAM
Package
TSOP-II
Plating
Gold
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume any responsibility for use of
circuits described. No patent licenses are implied.
Rev. 0.1/Apr.01
