HY51V(S)64403HG/HGL

16M x 4Bit EDO DRAM

PRELIMINARY

DESCRIPTION

This familiy is a 64Mbit dynamic RAM organized 16,777,216 x 4 bit configuration with Extended Data Out

mode CMOS DRAMs. Extended data out mode is a kind of page mode which is useful for the read opera-

tion. The advanced circuit and process allow this device to achieve high performance and low power dissi-

pation. Features are access time(45ns or 50ns) and refresh cycle(8K ref ) and power consumption

(Normal or low power with self refresh).

Advanced CMOS process as well as circuit techniques for wide operating margins allow this device to

achieve high speed access and high reliability

FEATURES

鈥?/div>

Extended data out operation

Read-modify-write capability

Multi-bit parallel test capability

LVTTL(3.3V) compatible inputs and outputs

/RAS only, CAS-before-/RAS, Hidden and self

refresh(L-version) capability

鈥?/div>

JEDEC standard pinout

32pin plastic SOJ/TSOP-II(400mil)

Single power supply of 3.3V +/- 10%

Battery back up operation(L-version)

鈥?/div>

Fast access time and cycle time

Part No

HY51V(S)64403HG/HGL-45

HY51V(S)64403HG/HGL-5

HY51V(S)64403HG/HGL-6

tRAC

45ns

50ns

60ns

tAA

23ns

25ns

30ns

tCAC

12ns

13ns

15ns

tRC

74ns

84ns

104ns

tHPC

17ns

20ns

25ns

鈥?/div>

Power dissipation

45ns

Active

Standby

352mW

50ns

312mW

60ns

278mW

鈥?/div>

Refresh cycle

Part No

HY51V64403HG*

HY51V64403HGL**

Ref

8K

Normal

64ms

128ms

L-part

1.8mW(CMOS level Max)

0.72mW (L-version : Max)

* Normal : /RAS only ref : 8K/64ms, CBR & Hidden ref : 4K /64ms

** L-part : /RAS only ref : 8K 128ms, CBR & Hidden ref : 4K/128ms

ORDERING INFORMATION

Part Number

HY51V(S)64403HG/HG(L)J-45

HY51V(S)64403HG/HG(L)J-5

HY51V(S)64403HG/HG(L)J-6

HY51V(S)64403HG/HG(L)T-45

HY51V(S)64403HG/HG(L)T-5

HY51V(S)64403HG/HG(L)T-6

(S) : Self refresh,

(L) : Low power

Access Time

45ns

50ns

60ns

45ns

50ns

60ns

Package

400mil 32pin SOJ

400mil 32pin TSOP-II

This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume any

responsibility for use of circuits described. No patent licenses are implied.

Rev.0.1/Apr.01
