HWD2108 Datasheet

  • HWD2108

  • Dual 105 mW Headphone Amplifier

  • 18頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HWD2108
Audio Power Amplifier
Dual 105 mW Headphone Amplifier
General Description
The
HWD2108
is
a
dual audio power amplifier capable of
delivering 105mW per channel of continuous average power
into a 16鈩?load with 0.1% (THD+N) from a 5V power supply.
audio power amplifiers were designed specifically to
provide high quality output power with a minimal amount of
external components using surface mount packaging. Since
the
HWD2108
does not require bootstrap capacitors or snub-
ber networks, it is optimally suited for low-power portable
systems.
The unity-gain stable
HWD2108
can be configured by external
gain-setting resistors.
Key Specifications
n
THD+N at 1kHz at 105mW continuous average output
power into 16鈩?/div>
0.1% (typ)
n
THD+N at 1kHz at 70mW continuous average output
power into 32鈩?/div>
0.1% (typ)
n
Output power at 0.1% THD+N at 1kHz into 32鈩?70mW
(typ)
Features
n
n
n
n
n
LLP, MSOP, and SOP surface mount packaging
Switch on/off click suppression
Excellent power supply ripple rejection
Unity-gain stable
Minimum external components
Applications
n
Headphone Amplifier
n
Personal Computers
n
Portable electronic devices
Typical Application
*Refer to the
Application Information
Section for information concerning proper selection of the input and output coupling capacitors.
FIGURE 1. Typical Audio Amplifier Application Circuit
1
