ADE-208-380A(Z)
HVM131SR
Silicon Epitaxial Planar Pin Diode
for Antenna Switching
Rev. 1
Oct. 1995
Features
鈥?Low capacitance.(C=0.8pF max)
鈥?Low forward resistance. (r
f
=1.0鈩?max)
鈥?MPAK package is suitable for high density
surface mounting and high speed assembly.
2
Outline
3
1
Ordering Information
Type No.
HVM131SR
Laser Mark
P6
Package Code
MPAK
(Top View)
1 Anode 1
2 Cathode 2
3 Cathode 1
Anode 2
Absolute Maximum Ratings
(Ta = 25擄C)
Item
Peak reverse voltage
Reverse voltage
Forward current
Power dissipation
Junction temperature
Storage temperature
* Two device total
Symbol
V
RM
V
R
I
F
*
P
d
*
T
j
Tstg
Value
65
60
100
150
125
-55 to +125
Unit
V
V
mA
mW
擄C
擄C
Electrical Characteristics
(Ta = 25擄C)
*
Item
Forward voltage
Reverse current
Capacitance
Forward resistance
* Per one device
Symbol
V
F
I
R
C
r
f
Min
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Max
1.0
0.1
0.8
1.0
Unit
V
碌A(chǔ)
pF
鈩?/div>
Test Condition
I
F
= 10 mA
V
R
= 60 V
V
R
= 1 V , f = 1 MHz
I
F
= 10 mA, f = 100 MHz
