105Vrms ring signal
Output over current protection
5.0V CMOS logic control
Logic enable/disable to save power
Adjustable deadband in single-control mode
Power-on reset
Fault output for problem detection
General Description
The Supertex HV430 is a high voltage PWM ring generator
integrated circuit. The high voltage outputs, V
PGATE
and V
NGATE
,
are used to drive the gates of external high voltage P-channel
and N-channel MOSFETs in a push-pull configuration. Over
current protection is implemented for both the P-channel and N-
channel MOSFETs. External sense resistors set the over-cur-
rent trip point.
The RESET input functions as a power-on reset when connected
to an external capacitor.
The FAULT output indicates an over-current condition and is
cleared after 4 consecutive cycles with no overcurrent condition.
A logic low on RESET or ENABLE clears the FAULT output. It is
active-low and open-drain to allow wire OR鈥檌ng of multiple
drivers.
P
gate
and N
gate
are controlled independently by logic inputs P
IN
and
N
IN
when the MODE pin is at logic high. A logic high on P
IN
will turn
on the external P-channel MOSFET. Similarly, a logic high on N
IN
will turn on the external N-channel MOSFET. Lockout circuitry
prevents the N and P switches from turning on simultaneously.
A pulse width limiter restricts pulse widths to no less than 100-
200ns.
+340V
+220V
+220V
-220V
-220V
+7.5V
-65擄C to +150擄C
600mW
For applications where a single control input is desired, the
MODE pin should be connected to SGND. The PWM control
signal is then input to the N
IN
pin. A user-adjustable deadband in
the control logic ensures break-before-make on the outputs,
thus avoiding cross conduction on the high voltage output during
switching. A logic high on N
IN
will turn the external P-Channel
MOSFET on and the N-Channel off, and vice versa. The IC can
be powered down by applying a logic low on the ENABLE pin,
placing both external MOSFETs in the off state.
Applications
鉂?/div>
鉂?/div>
Line access cards
Set-top/Street box
Absolute Maximum Ratings
V
PP1
鈥?V
NN1
, power supply voltage
V
PP1
, positive high voltage supply
V
PP2
, positive gate voltage supply
V
NN1
, negative high voltage supply
V
NN2
, negative gate voltage supply
V
DD
, logic supply
Storage temperature
Power dissipation
12/13/01
