New
It is contributed to the optical pickups of CD-R/RW and to simplify the production process
Hologram Unit for CD-R/RW Drivers
HUH7282 / HUH7283
!
Overview
The hologram units HUH7282/HUH7283 for CD-R/RW are
incorporating a high power laser diode, a photo detector , and
hologram element into a single package. It is developed real with
window structured high power laser diode, and realized high
speed recording. Moreover it is contributed to shorten the
development period for the optical pickups of CD-R/RW, and to
simplify the production process because of its compact package
for the slim drive.
0.3max
Unit : mm
3.95
+0
蠁8.5
-0.05
0.5鹵0.1脳7=
3.5鹵0.1
0.25
1.33
0.78
(0.3)
"
Window structured high power laser diode ideal for high speed
recording.
"
Recordable
脳24
speed + Readable
脳48
speed for
CD-ROM / RW disks
"
Focus error signal detection : SSD method
"
Tracking error signal detection : 3-beam method
"
Fast response ( fc=65 MHz)
8.8鹵0.2
(3.0)
(5.0)
!
Feature
0.3鹵0.1
12.2鹵0.3
0.1max
(0.52)
(2.3)
3.1鹵0.4
!
Applications
"
CD-R / RW Drives ( Recordable and Rewritable )
"
Combination drive
!
Specifications
HUH7282
Threshold current
Operating current銆€
Optical power output
Playback speed
Recording speed
Tracking error signal outoput pin count
Package size
Pin count
4
16
26 mA
110 mA
錛坅t
cw 90 mW)
150 mW
48 times
錛圔uilt-in
add amp錛?/div>
24 times
2
4.0 mm脳8.8 mm脳4.4 mm
HUH7283
The products and specification are subject to change without any notice. Please ask for the latest Product Standards to guarantee the satisfaction of your product requirements.
1.Kotari Yakemachi, Nagaokakyo, Kyoto, 617-8520 Japan
M00476AE
Tel. (075)951-8151
http://www.panasonic.co.jp/semicon
New publication, effective from Oct.1 2001.
1
