Total Power Dissipation (Tc=25擄C) ..................................................................................... 65 W
Total Power Dissipation (Ta=25擄C) ....................................................................................... 2 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage.................................................................................... -100 V
BVCEO Collector to Emitter Voltage................................................................................. -100 V
BVEBO Emitter to Base Voltage........................................................................................... -5 V
IC Collector Current.............................................................................................................. -6 A
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
ICES
ICEO
IEBO
*VCE(sat)
*VBE(on)
*hFE1
*hFE2
fT
Min.
-100
-100
-
-
-
-
-
30
15
3
Typ.
-
-
-
-
-
-
-
-
-
-
Max.
-
-
-400
-700
-1
-1.5
-2
-
75
-
Unit
V
V
uA
uA
mA
V
V
Test Conditions
IC=-1mA, IE=0
IC=-30mA, IB=0
VCE=-100V
VCE=-60V
VEB=-5V
IC=-6A, IB=-600mA
IC=-6A, VCE=-4V
IC=-0.3A, VCE=-4V
IC=-3A, VCE=-4V
IC=-0.1A, VCE=-5V, f=1MHz
*Pulse Test: Pulse Width
鈮?80us,
Duty Cycle鈮?%
MHz
HTIP42C
HSMC Product Specification
1
