Total Power Dissipation (Tc=25擄C) ..................................................................................... 40 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage..................................................................................... 100 V
BVCEO Collector to Emitter Voltage.................................................................................. 100 V
BVEBO Emitter to Base Voltage............................................................................................ 5 V
IC Collector Current............................................................................................................... 3 A
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
ICES
ICEO
IEBO
*VCE(sat)
*VBE(on)
*hFE1
*hFE2
fT
Min.
100
100
-
-
-
-
-
25
10
3
Typ.
-
-
-
-
-
-
-
-
-
-
Max.
-
-
200
300
1
1.2
1.8
-
50
-
Unit
V
V
uA
uA
mA
V
V
Test Conditions
IC=1mA, IE=0
IC=30mA, IC=0
VCE=100V, IB=0
VCE=60V, IB=0
VEB=5V, IC=0
IC=3A, IB=375mA
IC=3A, VCE=4V
IC=1A, VCE=4V
IC=3A, VCE=4V
IC=0.5A, VCE=10V, f=1MHz
*Pulse Test: Pulse Width
鈮?80us,
Duty Cycle鈮?%
MHz
HTIP31C
HSMC Product Specification
1
2
3
