Total Power Dissipation (Tc=25擄C)................................................................................................. 50 W
Total Power Dissipation (Ta=25擄C)................................................................................................... 2 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage ................................................................................................. 100 V
BVCEO Collector to Emitter Voltage .............................................................................................. 100 V
BVEBO Emitter to Base Voltage ....................................................................................................... 5 V
IC Collector Current (Continue) ......................................................................................................... 4 A
IC Collector Current (Peak)................................................................................................................ 6 A
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
ICBO
ICEO
IEBO
*VCE(sat)
*VBE(on)
*hFE1
*hFE2
Cob
Min.
100
100
-
-
-
-
-
1
500
-
Typ.
-
-
-
-
-
-
-
-
-
-
Max.
-
-
1
2
2
2.5
2.8
-
-
200
Unit
V
V
mA
mA
mA
V
V
K
pF
Test Conditions
IC=1mA
IC=30mA
VCB=100V
VCE=50V
VEB=5V
IC=2A, IB=8mA
IC=2A, VCE=4V
IC=1A, VCE=4V
IC=2A, VCE=4V
VCB=10V, f=0.1MHz
*Pulse Test: Pulse Width
鈮?80us,
Duty Cycle鈮?%
Darlington Schematic
C
B
R1
R2
E
HTIP112
HSMC Product Specification
