Total Power Dissipation (Ta=25擄C) ................................................................................ 625 mW
鈥?/div>
Maximum Voltages and Currents (Ta=25擄C)
BVCBO Collector to Base Voltage....................................................................................... 75 V
BVCEO Collector to Emitter Voltage.................................................................................... 40 V
BVEBO Emitter to Base Voltage............................................................................................ 6 V
IC Collector Current........................................................................................................ 600 mA
Characteristics
(Ta=25擄C)
Symbol
BVCBO
*BVCEO
BVEBO
ICBO
ICEX
IEBO
*VCE(sat)1
*VCE(sat)2
*VBE(sat)1
*VBE(sat)2
*hFE1
*hFE2
*hFE3
*hFE4
*hFE5
*hFE6
fT
Min.
75
40
6
-
-
-
-
-
-
-
35
50
75
100
40
50
300
Typ.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Max.
-
-
-
10
10
50
300
1
1.2
2
-
-
-
300
-
-
-
Unit
V
V
V
nA
nA
nA
mV
V
V
V
-
-
-
-
-
-
MHz
Test Conditions
IC=10uA
IC=100mA
IE=10uA
VCB=60V
VCB=60V, VEB(off)=3V
VEB=3V
IC=150mA, IB=15mA
IC=500mA, IB=50mA
IC=150mA, IB=15mA
IC=500mA, IB=50mA
VCE=10V, IC=100uA
VCE=10V, IC=1mA
VCE=10V, IC=10mA
VCE=10V, IC=150mA
VCE=10V, IC=500mA
VCE=1V, IC=150mA
IC=20mA VCE=20V, f=100MHz
*Pulse Test: Pulse Width
鈮?80us,
Duty Cycle鈮?%
HSMC Product Specification
1
2
3
