HT49C30L Datasheet

  • HT49C30L

  • 8-Bit LCD Type MCU

  • 348.79KB

  • 43頁

  • HOLTEK

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HT49R30A-1/HT49C30-1/HT49C30L
8-Bit LCD Type MCU
Features
路
Operating voltage:
路
On-chip crystal, RC and 32768Hz crystal oscillator
路
HALT function and wake-up feature reduce power
2.2V~5.5V for HT49R30A-1/HT49C30-1
1.2V~2.2V for HT49C30L
路
6 input lines
路
8 bidirectional I/O lines
路
Two external interrupt input
路
One 8-bit programmable timer/event counter with
consumption
路
4-level subroutine nesting
路
Bit manipulation instruction
路
14-bit table read instruction
路
Up to 0.5ms instruction cycle with 8MHz system clock
PFD (programmable frequency divider) function
路
LCD driver with 19麓2, 19麓3 or 18麓4 segments
路
2K麓14 program memory ROM
路
96麓8 data memory RAM
路
Real Time Clock (RTC)
路
8-bit prescaler for RTC
路
Watchdog Timer
路
Buzzer output
for HT49R30A-1/HT49C30-1
路
Up to 8ms instruction cycle with 500kHz system clock
for HT49C30L
路
63 powerful instructions
路
All instructions in 1 or 2 machine cycles
路
Low voltage reset/detector for
HT49R30A-1/HT49C30-1
路
48-pin SSOP package
General Description
The HT49C30-1 and the HT49C30L are 8-bit high per-
f or m a nce si ngl e c hi p m i c ro c o n tr o l l e r s . T h e
HT49R30A-1 is the OTP version of the HT49C30-1. Its
single cycle instruction and two-stage pipeline architec-
ture make it suitable for high speed applications. The
devices are also suitable for use in multiple LCD low
power applications such as scales, leisure products,
high-level household appliances, hand held LCD prod-
ucts and batteries operated systems in particular.
Rev. 1.10
1
September 25, 2002
