HT46C63(100QFP) Datasheet

  • HT46C63(100QFP)

  • Microcontroller

  • 358.66KB

  • 42頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HT46R63/HT46C63
8-Bit A/D with LCD Type MCU
Features
路
Operating voltage: 2.2V~5.5V
路
Operating frequency: External RC or Crystal
路
32.768kHz crystal oscillator used for timing purposes
路
Watchdog enable or disable function
路
1x16 bits timer with an overflow interrupt (TMR)
路
Time base generator (clock source: 32.768kHz)
路
Up to 0.5ms instruction cycle with 8MHz system clock
at V
DD
=5V
路
2 external interrupts (high/low going trigger)
路
One comparator
路
LCD: 20麓3 or 19麓4, 1/3 bias with 12 pins logical
and RTC interrupts
路
4K麓15 program memory ROM
路
208麓8 data memory RAM
路
Maximum of 32 I/O lines (shared with INT0, INT1,
outputs options. (select by options in unit of 4 pins,
麓8
high sink)
路
Built-in R type bias generator
路
8 channels 8-bits resolution (7-bit accuracy) A/D
converter
路
4 channels PWM outputs
路
100-pin QFP package
TMR, AN0~AN7, PWM0~PWM3)
路
8-level stack
General Description
The device is an 8-bit high performance RISC-like
microcontroller designed for multiple I/O product appli-
cations. It is particularly suitable for use in products
such as washing machine controllers, camera control-
lers and home appliances with LCD display. A HALT
feature is included to reduce power consumption.
Rev. 1.00
1
September 9, 2002
