HT1602L Datasheet

IC型號：
HT1602L
PDF描述：
40 Dot Matrix LCD Segment Driver
文件大小：
230.76KB
PDF頁數：
6頁
芯片廠家：
HOLTEK

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HT1602L

40 Dot Matrix LCD Segment Driver

Features

鈥?/div>

Operating voltage: 2.7V~5.5V

LCD driving voltage: 3.0V~5.2V

Applicable LCD duty from 1/8 to 1/16

Suitable for various types of LCD panel

Bias voltage adjustable from an external

source

Applications

鈥?/div>

Interface with HT163A

Electronic dictionaries

Portable computers

鈥?/div>

Remote controllers

Calculators

General Description

The HT1602L is a dot matrix LCD segment

driver LSI implemented in CMOS technology.

The chip contains 40-bit shift register (two 20-

bit shift registers), 40-bit latch (two 20-bit

latches), 40-bit level shifter, 40-bit 4-level

driver and control circuits.

The HT1602L can convert serial data received

from an LCD controller parallel data and then

send them out as LCD driving waveforms to the

LCD panel. The chip is applicable up to 1/16

duty. Furthermore, the bias voltage which de-

termines the LCD driving voltage can be option-

ally supplied from an external source, thus the

chip is suitable for driving various LCD panel.

These special features increase the versatility

of the chip.

Block Diagram
