HTMOS
TM
High Temperature Products
HIGH TEMPERATURE QUAD ANALOG SWITCH
FEATURES
鈥?Specified Over -55 to +225擄C
鈥?Worst Case Leakage 500 nA at 225擄C
鈥?Low Control Input Current
鈥?High Degree of Linearity
鈥?Low Crosstalk Between Switches
鈥?Hermetic 14-Lead Ceramic DIP
鈥?Latchup Free Design with Dielectric Isolation
鈥?Individual Switch Controls
鈥?CMOS Logic Levels
HT1204
APPLICATIONS
鈥?Down-Hole Oil Well
鈥?Avionics
鈥?Turbine Engine Control
鈥?Industrial Process Control
鈥?Nuclear Reactor
鈥?Electric Power Conversion
鈥?Heavy Duty Internal Combustion Engines
GENERAL DESCRIPTION
The HT1204 monolithic quad analog switch consists of
four independently controlled switches capable of switch-
ing either analog or digital signals over an extremely wide
temperature range. It is fabricated with Honeywell鈥檚
dielectrically isolated high temperature (HTMOS鈩? linear
process, and is designed specifically for use in systems
operating in severe high temperature environments. All
parts are burned in at 250擄C to eliminate infant mortality.
These switches provide guaranteed performance over
the full -55 to +225擄C temperature range. Typically, parts
will operate up to +300擄C for a year, with derated perfor-
mance. High temperature applications such as signal
gating, chopping, modulation, demodulation and multi-
plexing are all possible with the HT1204.
PACKAGE PINOUT
IN/OUT A
1
14
V
DD
OUT/IN A
2
13
CONTROL A
OUT/IN B
3
12
CONTROL D
IN/OUT B
4
11
IN/OUT D
CONTROL B
5
10
OUT/IN D
CONTROL C
6
9
OUT/IN C
V
SS
7
8
IN/OUT C
Top View
14-Lead Cerdip
胃jc
= 9擄C/W
Solid State Electronics Center 鈥?12001 State Highway 55, Plymouth, MN 55441 鈥?(800) 323-8295 鈥?http://www.ssec.honeywell.com
