ADE-208-025A(Z)
HSM113WK
Silicon Schottky Barrier Diode
for Battery Switch
Preliminary
Rev.1
Apr. 1993
Features
鈥?The HSM113WK has two different (V
F
- I
F
)
chips, and can change the main battery to the
backup battery automatically.
鈥?MPAK package is suitable for high density
surface mounting and high speed assembly.
2
Pin Arrangement
3
1
Ordering Information
Type No.
HSM113WK
Laser Mark
S12
Package Code
MPAK
(Top View)
1 Anode
2 Anode
3 Cathode
Absolute Maximum Ratings
(Ta = 25擄C)
Item
Peak reverse voltage
Forward current
Non-Repetitive peak forward surge current
Symbol
V
RM
I
F
I
FSM
*
T
j
Tstg
Junction temperature
Storage temperature
* 10msec, 1 pulse square wave
Value
Pin 1-3
20
200
2
125
-55 to +125
Value
Pin 2-3
20
100
0.6
125
-55 to +125
Unit
V
mA
A
擄C
擄C
Electrical Characteristics
(Ta = 25擄C)
Item
Forward voltage
Forward voltage
Reverse current
Symbol
V
F1
V
F2
I
R
Pin 1-3
Pin 2-3
Pin 1-3
Pin 2-3
Pin 1-3
Pin 2-3
Min
鈥?/div>
1.2
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Max
0.35
1.8
0.55
3.0
10
1.0
Unit
V
V
碌A(chǔ)
Test Condition
I
F
= 10mA
I
F
= 200mA
I
F
= 100mA
V
R
= 5 V
V
R
= 20V
