DC COMPONENTS CO., LTD.
R
HSM101
THRU
HSM106
RECTIFIER SPECIALISTS
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT HIGH EFFICIENCY RECTIFIER
VOLTAGE RANGE - 50 to 600 Volts
CURRENT - 1.0 Ampere
FEATURES
*
*
*
*
ldeal for surface mounted applications
Low leakage current
Fast switching for high efficiency
Glass passivated junction
SM-1(DO-213AB)
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
*Terminals: Solder plated solderable per
MIL-STD-202E, Method 208 guaranteed
* Polarity: Color band denotes cathode end
* Mounting position: Any
* Weight: 0.12 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Volts
Maximum DC Blocking Voltage
Maximum Average Forward Current
at T
A
= 50
o
C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Instantaneous Forward Voltage at 1.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Maximum Reverse Recovery Time (Note 1)
Typical Junction Capacitance (Note 2)
Operating and Storage Temperature Range
NOTES : 1. Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A.
2. Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts.
@T
A
= 25
o
C
@T
A
=125
o
C
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
trr
C
J
T
J
, T
STG
HSM101 HSM102 HSM103 HSM104 HSM105 HSM106
50
35
50
100
70
100
200
140
200
1.0
30
1.0
5.0
100
50
15
-65 to + 175
75
1.3
1.7
300
210
300
400
280
400
600
420
600
UNITS
Volts
Volts
Volts
Amps
Amps
Volts
uAmps
nSec
pF
0
C
