ADE-208-173A(Z)
HSK277
Silicon Epitaxial Planar Diode
for UHF/VHF tuner Band Switch
Rev. 1
Jun. 1994
Features
鈥?Low forward resistance. (r
f
= 0.5鈩?max)
鈥?LLD package is suitable for high density surface
mounting and high speed assembly.
1
2nd. band
Cathode band
Outline
Cathode band
2
Ordering Information
Type No. Cathode Band 2nd Band Package code
HSK277 Verdure
Blue
LLD
1
2nd. band
2
1. Cathode
2. Anode
Absolute Maximum Ratings
(Ta = 25擄C)
Item
Reverse voltage
Forward current
Power dissipation
Operation temperature
Storage temperature
Symbol
V
R
I
F
P
d
Topr
Tstg
Value
35
100
150
-20 to + 60
-55 to +150
Unit
V
mA
mW
擄C
擄C
Electrical Characteristics
(Ta = 25擄C)
Item
Forward voltage
Reverse voltage
Reverse current
Capacitance
Forward resistance
Symbol
V
F
V
R
I
R
C
r
f
Min
鈥?/div>
35
鈥?/div>
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Max
1.0
鈥?/div>
10
1.2
0.5
Unit
V
V
nA
pF
鈩?/div>
Test Condition
I
F
= 10 mA
I
R
= 10 碌A
V
R
= 25 V
V
R
= 6 V , f = 1 MHz
I
F
= 2 mA , f = 100 MHz
