19-3013; Rev 0; 10/03
HS I
2
C-Compatible Module
General Description
The HS I
2
C鈩?compatible module is a reference solution
for implementing an interface that is compatible with the
high-speed (HS) mode (3.4MHz, 1.7MHz), fast mode
(400kHz), and standard mode (100kHz) of the I
2
C stan-
dard. The module consists primarily of an Altera
EPM3256AQC208-10 programmable logic device (PLD)
containing the DI2CM core available from Digital Core
Design. The module allows microcontrollers (碌Cs) with a
compatible 8-bit-memory-mapped parallel interface to
communicate with I
2
C-compatible slave devices.
The HS I
2
C-compatible module is provided as part of
selected Maxim evaluation systems. The main purpose
of the HS I
2
C-compatible module is the evaluation of
Maxim products. The use of the HS I
2
C-compatible
module as a development board or any other use not
described in selected Maxim evaluation kit (EV kit)/
evaluation system (EV system) data sheets is not sup-
ported by Maxim.
Features
o
HS-Mode I
2
C-Compatible Interface (3.4MHz, 1.7MHz)
o
Fast-Mode I
2
C-Compatible Interface (400kHz)
o
Standard-Mode I
2
C-Compatible Interface (100kHz)
o
Proven Design
o
Proven PC Board Layout
o
On-Board 40MHz Crystal Oscillator
o
On-Board Regulated +3.3V
Evaluates: HS I
2
C-Compatible Parts
Ordering Information
PART NUMBER
HSI2CMOD
INTERFACE TYPE
HS/Fast/Standard-Mode I
2
C-Compatible
Component List
DESIGNATION QTY
C1鈥揅15, C19,
C20, C21
18
DESCRIPTION
0.1碌F 鹵10%, 16V X7R ceramic
capacitors (0603)
TDK C1608X7R1C104KT
1碌F 鹵20%, 10V X5R ceramic
capacitor (0805)
TDK C2012X5R1A105M
10碌F 鹵20%, 25V X5R ceramic
capacitor (1210)
TDK C3225X5R1E106M
100碌F, 6.3V, 45m鈩?low-ESR POSCAP
(D2)
Sanyo 6TPC100M
1A, 30V Schottky diode
Nihon EP10QY03
Surface-mount ferrite beads (0603)
TDK MMZ1608B601C
Not installed,10-pin, 2 x 5 header
20-pin, 2 x 10 male right-angle
connector
2 x 20 right-angle female connector
3-pin headers
2-pin headers
10碌H inductor
Sumida CDRH6D28-100NC
DESIGNATION QTY
R1, R2
R3, R4, R7
R5
R6
SW1
2
3
1
1
1
DESCRIPTION
1.5k鈩?鹵5% resistors (1206)
(suitable for a 2-wire bus capacitance
of
鈮?/div>
200pF)
0鈩?鹵5% resistors (1206)
165k鈩?鹵1% resistor (0603)
100k鈩?鹵1% resistor (0603)
DIP switch default:
SW: 1-4 (ON)
SW: 2-3 (ON)
Altera EPM3256AQC208-10
(208-pin PQFP)
Step-down regulator (8-pin 碌MAX)
Maxim MAX1776EUA
40MHz crystal oscillator (half-size DIP)
Oscilent 320-40.0M-5E-TTS
Tri-state logic buffer (5-pin SOT23)
Fairchild Semiconductor
NC7SZ126M5X
Schmitt trigger input-logic inverters
(5-pin SOT23)
Fairchild Semiconductor
NC7SZ14M5X
Shunts
C16
1
C17
1
C18
1
U1
U2
U3
1
1
1
D1
FB1, FB2
J1
J2
J3
JU1, JU2, JU5
JU3, JU4, JU6,
JU7, JU8
L1
1
2
1
1
1
3
5
1
U4
1
U5, U6, U7
3
None
5
Purchase of I
2
C components of Maxim Integrated Products,
Inc. or one of its sublicensed Associated Companies, conveys
a license under the Phillips I
2
C Patent Rights to use these
components in an I
2
C system, provided that the system con-
forms to the I
2
C Standard Specification as defined by Phillips.
1
________________________________________________________________
Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
