HSDL-3002-007 Datasheet

  • HSDL-3002-007

  • IrDA Data Compliant 115.2Kb/s with Remote Control Transmissi...

  • 20頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Agilent HSDL-3002
IrDA
廬
Data Compliant Low Power
115.2 kbit/s with Remote Control
Transmission Infrared Transceiver
Data Sheet
General Features
鈥?Guaranteed temperature
performance, 鈥?0 to 70擄C
鈥?Critical parameters are guaran-
teed over temperature and supply
voltage
鈥?Low power consumption
鈥?Small module size
鈥?Height: 2.70 mm
鈥?Width: 9.10 mm
鈥?Depth: 3.65 mm
鈥?Withstands >100 mV
p-p
power
supply ripple typically
鈥?V
CC
supply 2.7 to 5.5 volts
鈥?Integrated EMI shield
鈥?Designed to accommodate light
loss with cosmetic windows
鈥?IEC 825-class 1 eye safe
IrDA Data Features
鈥?Fully compliant to IrDA physical
layer specifications version 1.4 from
9.6 kbit/s to 115.2 kbit/s
鈥?Excellent nose-to-nose operation
鈥?Link distance up to 50 cm
鈥?Complete shutdown for TXD(IrDA),
RXD(IrDA), and PIN diode
鈥?Low shutdown current (10 nA
typical)
鈥?LED stuck-high protection
Remote Control Features
鈥?High radiant intensity
鈥?Spectrally suited to remote
control receiver
鈥?Typical link distance at 6 m
Applications
鈥?Mobile data communication and
universal remote control
鈥?PDAs
鈥?Mobile phone
Description
The HSDL-3002 is a small form
factor single enhanced infrared (IR)
transceiver module that provides
the combination of (1) interface
between logic and IR signals for
through-air, serial, half-duplex IR
data link, and (2) IR remote control
transmission operating at 940 nm
for universal remote control
applications.
For infrared data communication,
the HSDL-3002 provides the
flexibility of Low Power SIR
applications and remote control
applications depending on the
application circuit designs as
outlined in the Application
Circuit section. The transceiver is
compliant to IrDA Physical Layer
Specifications version 1.4 from
9.6 kbit/s to 115.2 kbit/s and it is
IEC 825-Class 1 Eye Safe.
The HSDL-3002 can be shutdown
completely to achieve very low
power consumption. In the
shutdown mode, the PIN diode
will be inactive and thus
producing very little photo-
current even under very bright
ambient light. Such features are
ideal for battery operated
handheld products.
