Total Power Dissipation (Ta=25擄C) ....................................................................................... 1 W
Total Power Dissipation (Tc=25擄C) ..................................................................................... 10 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage....................................................................................... 40 V
BVCEO Collector to Emitter Voltage.................................................................................... 30 V
BVEBO Emitter to Base Voltage............................................................................................ 5 V
IC Collector Current (DC) ...................................................................................................... 3 A
IC Collector Current (Pulse) ................................................................................................. 7 A
IB Base Current (DC) ......................................................................................................... 0.6 A
Electrical Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
BVEBO
ICBO
IEBO
*VCE(sat)
*VBE(sat)
*hFE1
*hFE2
fT
Cob
Min.
40
30
5
-
-
-
-
30
100
-
-
Typ.
-
-
-
-
-
0.3
1
150
200
90
45
Max.
-
-
-
1
1
0.5
2
-
500
-
-
Unit
V
V
V
uA
uA
V
V
Test Conditions
IC=100uA
IC=1mA
IE=10uA
VCB=30V
VEB=3V
IC=2A, IB=0.2A
IC=2A, IB=0.2A
IC=20mA, VCE=2V
IC=1A, VCE=2V
IC=0.1A, VCE=5V
VCB=10V, f=1MHz, IE=0
*Pulse Test: Pulse Width
鈮?80us,
Duty Cycle鈮?%
MHz
pF
Classification Of hFE2
Rank
Range
Q
100-200
P
160-320
E
250-500
HSD882
HSMC Product Specification
