Total Power Dissipation (Tc=25擄C) .................................................................................... 30 W
Total Power Dissipation (Ta=25擄C) ................................................................................... 1.5 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage ...................................................................................... 60 V
BVCEO Collector to Emitter Voltage................................................................................... 60 V
BVEBO Emitter to Base Voltage ........................................................................................... 7 V
IC Collector Current .............................................................................................................. 3 A
IB Base Current ................................................................................................................. 0.5 A
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
ICBO
IEBO
*VCE(sat)
*VBE(on)
*hFE
fT
Min.
60
60
-
-
-
-
60
-
Typ.
-
-
-
-
-
-
-
3
Max.
-
-
100
100
1
1
300
-
Unit
V
V
uA
uA
V
V
MHz
Test Conditions
IC=1mA, IE=0
IC=50mA, IB=0
VCB=60V, IE=0
VEB=7V, IC=0
IC=3A, IB=0.3A
IC=0.5A, VCE=5V
IC=0.5A, VCE=5V
IC=500mA, VCE=5V
*Pulse Test : Pulse Width
鈮?80us,
Duty Cycle鈮?%
Classification Of hFE
Rank
Range
O
60-120
Y
100-200
GR
150-300
HSMC Product Specification
1
2
3
