Total Power Dissipation (Ta=25擄C) ............................................................................... 900 mW
鈥?/div>
Maximum Voltages and Currents (Ta=25擄C)
VCBO Collector to Base Voltage ....................................................................................... -25 V
VCEO Collector to Emitter Voltage .................................................................................... -20 V
VEBO Emitter to Base Voltage ............................................................................................ -5 V
IC Collector Current ............................................................................................................ -1 A
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
BVEBO
ICBO
*VCE(sat)
VBE(on)
*hFE
fT
Cob
Min.
-25
-20
-5
-
-
-
85
-
-
Typ.
-
-
-
-
-
-
-
350
38
Max.
-
-
-
-1
-500
-1
240
-
-
Unit
V
V
V
uA
mV
V
MHz
pF
Test Conditions
IC=-10uA, IE=0
IC=-1mA, IB=0
IE=-10uA, IC=0
VCB=-20V, IE=0
IC=-800mA, IB=-80mA
IC=-500mA, VCE=-2V
VCE=-2V, IC=-500mA
VCE=-2V, IC=-500mA
VCB=-10V, f=1MHz
*Pulse Test : Pulse Width
鈮?80us,
Duty Cycle鈮?%
Classification Of hFE
Rank
Range
B
85-170
C
120-240
HSMC Product Specification
