Total Power Dissipation (Tc=25擄C) .................................................................................... 30 W
Total Power Dissipation (Ta=25擄C) ...................................................................................... 2 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage ..................................................................................... -60 V
BVCEO Collector to Emitter Voltage.................................................................................. -60 V
BVEBO Emitter to Base Voltage .......................................................................................... -5 V
IC Collector Current ............................................................................................................. -3 A
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
BVEBO
ICBO
IEBO
ICEO
*VCE(sat)
*VBE(on)
*hFE1
*hFE2
fT
Min.
-60
-60
-5
-
-
-
-
-
40
40
-
Typ.
-
-
-
-
-
-
-
-
-
-
8
Max.
-
-
-
-100
-1
-5
-1
-1.5
-
320
-
Unit
V
V
V
uA
mA
mA
V
V
Test Conditions
IC=-1mA, IE=0
IC=-10mA, IB=0
IE=-1mA, IC=0
VCB=-20V, IE=0
VEB=-4V, IC=0
VCE=-60V, IB=0
IC=-2A, IB=-0.2A
IC=-1A, VCE=-2V
IC=-0.1A, VCE=-2V
IC=-1A, VCE=-2V
VCE=-5V, IC=-500mA, f=100MHz
*Pulse Test : Pulse Width
鈮?80us,
Duty Cycle鈮?%
MHz
Classification Of hFE2
Rank
hFE
C
40-80
D
60-120
E
100-200
F
160-320
HSMC Product Specification
1
2
3
