Total Power Dissipation (Ta=25擄C) .................................................................................. 1.25 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage.................................................................................... -160 V
BVCEO Collector to Emitter Voltage................................................................................. -160 V
BVEBO Emitter to Base Voltage........................................................................................... -5 V
IC Collector Current....................................................................................................... -100 mA
Electrical Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
BVEBO
ICBO
*VCE(sat)
VBE(on)
*hFE1
*hFE2
fT
Cob
Min.
-160
-160
-5
-
-
-
60
30
-
-
Typ.
-
-
-
-
-
-
-
-
140
5.5
Max.
-
-
-
-10
-2
-1.5
320
-
-
-
Unit
V
V
V
uA
V
V
Test Conditions
IC=-10uA
IC=-1mA
IE=-10uA
VCB=-140V
IC=-30mA, IB=-3mA
IC=-10mA, VCE=-5V
IC=-10mA, VCE=-5V
IC=-1mA, VCE=-5V
IC=-10mA, VCE=-5V
VCB=-10V, f=1MHz
*Pulse Test: Pulse Width
鈮?80us,
Duty Cycle鈮?%
MHz
pF
Classification Of hFE1
Rank
Range
B
60-120
C
100-200
D
160-320
HSB1109
HSMC Product Specification
1
2
3
