MODEL HS93 SERIES
T1/CEPT/ISDN
Transformers
NEW PRODUCT
FEATURES AND BENEFITS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Available in through-hole and surface mount packages
Designed for 1.544 Mbp/s (T1), 2.048 Mbps (CEPT) and ISDN primary rate interface (PRI) applications
Dual package contains both transmit and receive transformers
2000 V rms dielectric withstanding voltage
Models matched to leading tranceiver ICs
ELECTRICAL @ 25擄C
Part
Number
HS93-98706
HS93-98705
HS93-97725
HS93-97727
(1)
Turns Ratio
Primary:Secondary
鹵3%
(1)
1:1:1
1:2 ct & 1:1.36
1 ct:2 ct & 1 ct:2 ct
1:2 & 1:2
OCL
mH Min.
1.2
1.2 & 1.2
1.2 & 1.2
22 & 22
L
L
碌H Max.
0.5
0.5 & 0.8
0.6 & 0.6
11 & 11
Cww
pF Max.
25
35 & 35
35 & 35
100 & 100
Primary
DCR
鈩?/div>
Max.
0.70
0.8 & 0.8
0.7 & 0.7
2.4 & 2.4
Secondary
DCR
鈩?/div>
Max.
0.70 & 0.70
Primary
Pins
5-6
1.2 & 1.0 14-12 & 5-7
1.2 & 1.2 12-10 & 4-6
4.4 & 4.4
1-4 & 5-8
6
ENVIRONMENTAL
Operating Temperature Range
MECHANICAL
0擄C to +70擄C
Type
Lead Plating
Lead Material
Lead Con鏗乬uration
Lead Coplanarity
Case Material, UL-94V-0 Rated
Speci鏗乧ations subject to change without notice.
Note: (1) Turns ratio based on the shorting of pins 2-3, 6-7, 10-11 & 14-15.
Through Hole
60/40 Tin Lead
Copper Alloy
N/A
N/A
Molded Dap
Surface Mount
85/15 Tin Lead
Copper Alloy 42
Gull Wing
0.004鈥?(0.102mm)
Molded Epoxy
6-151
Model HS93 Series
