HS-2600RH
Data Sheet
August 1999
File Number
3650.1
Radiation Hardened Wideband, High
Impedance Operational Ampli鏗乪r
HS-2600RH is a radiation hardened internally compensated
bipolar operational ampli鏗乪r that features very high input
impedance coupled with wideband AC performance. The
high resistance of the input stage is complemented by low
offset voltage (4mV
max
at 25
o
C for HS-2600RH) and low
bias and offset current (10nA max at 25
o
C for HS-2600RH)
to facilitate accurate signal processing. Offset voltage can be
reduced further by means of an external nulling
potentiometer. The 4V/碌s minimum slew rate at 25
o
C and
the minimum open loop gain of 100kV/V at 25
o
C enables the
HS-2600RH to perform high gain ampli鏗乧ation of fast,
wideband signals. These dynamic characteristics, coupled
with fast settling times, make these ampli鏗乪rs ideally suited
to pulse ampli鏗乧ation designs as well as high frequency or
video applications. The frequency response of the ampli鏗乪r
can be tailored to exact design requirements by means of an
external bandwidth control capacitor. Other high
performance designs such as high gain, low distortion audio
ampli鏗乪rs, high-Q and wideband active 鏗乴ters and high
speed comparators, are excellent uses of this part.
Speci鏗乧ations for Rad Hard QML devices are controlled
by the Defense Supply Center in Columbus (DSCC). The
SMD numbers listed here must be used when ordering.
Detailed Electrical Speci鏗乧ations for these devices are
contained in SMD 5962-95671. A 鈥渉ot-link鈥?is provided
on our homepage for downloading.
www.intersil.com/spacedefense/space.asp
Features
鈥?Electrically Screened to SMD # 5962-95671
鈥?QML Quali鏗乪d per MIL-PRF-38535 Requirements
鈥?High Input Impedance . . . . . . . . . . . . . . . . . 100M鈩?(Min)
500M鈩?(Typ)
鈥?High Slew Rate. . . . . . . . . . . . . . . . . . . . . . . . 3V/碌s (Min)
7V/碌s (Typ)
鈥?Low Input Bias Current . . . . . . . . . . . . . . . . . . 10nA (Max)
1nA (Typ)
鈥?Low Input Offset Current (HS-2600RH) . . . . . . 4mV (Max)
鈥?Wide Unity Gain Bandwidth . . . . . . . . . . . . . .12MHz (Typ)
鈥?Output Short Circuit Protection
鈥?Total Gamma Dose. . . . . . . . . . . . . . . . . . . . . 10kRAD(Si)
Applications
鈥?Video Ampli鏗乪r
鈥?Pulse Ampli鏗乪r
鈥?High-Q Active Filters
鈥?High Speed Comparators
鈥?Low Distortion Oscillators
Pinout
HS7-2600RH (CERDIP) GDIP1-T8
OR
HS7B-2600RH (SBDIP) CDIP2-T8
TOP VIEW
Ordering Information
ORDERING NUMBER
5962D9567101VPA
5962D9567101VPC
INTERNAL
MKT. NUMBER
HS7-2600RH-Q
HS7B-2600RH-Q
TEMP. RANGE
(
o
C)
-55 to 125
-55 to 125
BAL
-IN
+IN
V-
1
2
3
4
8
COMP
V+
OUT
BAL
鈥?/div>
+
7
6
5
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143 | Copyright 漏 Intersil Corporation 1999
