HS-5104ARH
TM
Data Sheet
August 2001
File Number
3025.4
Radiation Hardened Low Noise Quad
Operational Amplifier
tle
-
4A
-
ia-
d-
The HS-5104ARH is a radiation hardened, monolithic quad
operational amplifier that provides highly reliable
performance in harsh radiation environments. Its excellent
noise characteristics coupled with an unique array of
dynamic specifications make this amplifier well-suited for a
variety of satellite system applications. Dielectrically
isolated, bipolar processing makes this device immune to
Single Event Latch-Up.
The HS-5104ARH shows almost no change in offset voltage
after exposure to 100kRAD(Si) gamma radiation, with only a
minor increase in current. Complementing these specifications
is a post radiation open loop gain in excess of 40K.
This quad operational amplifier is available in an industry
standard pinout, allowing for immediate interchangeability
with most other quad operational amplifiers.
Specifications for Rad Hard QML devices are controlled
by the Defense Supply Center in Columbus (DSCC). The
SMD numbers listed here must be used when ordering.
Detailed Electrical Specifications for these devices are
contained in SMD 5962-95690. A 鈥渉ot-link鈥?is provided
on our homepage for downloading.
http://www.intersil.com
Features
鈥?Electrically Screened to SMD # 5962-95690
鈥?QML Qualified per MIL-PRF-38535 Requirements
鈥?Radiation Environment
- Gamma Dose (緯) . . . . . . . . . . . . . . . . . 1 x 10
5
RAD(Si)
鈥?Low Noise
- At 1kHz . . . . . . . . . . . . . . . . . . . . . . . . 4.3nV/鈭欻z (Typ)
- At 1kHz . . . . . . . . . . . . . . . . . . . . . . . . 0.6pA/鈭欻z (Typ)
鈥?Low Offset Voltage . . . . . . . . . . . . . . . . . . . . .3.0mV (Max)
鈥?High Slew Rate . . . . . . . . . . . . . . . . . . . . . . 2.0V/碌s (Typ)
鈥?Gain Bandwidth Product . . . . . . . . . . . . . . . 8.0MHz (Typ)
se
d
ra-
al
pli-
tho
-
ds
r-
po-
n,
i-
or,
ia-
d-
,
Applications
鈥?High Q, Active Filters
鈥?Voltage Regulators
鈥?Integrators
鈥?Signal Generators
鈥?Voltage References
鈥?Space Environments
Ordering Information
ORDERING NUMBER
5962R9569001V9A
5962R9569001VCC
5962R9569001VXC
INTERNAL
MKT. NUMBER
HS0-5104ARH-Q
HS1-5104ARH-Q
HS9-5104ARH-Q
TEMP. RANGE
(
o
C)
25
-55 to 125
-55 to 125
-55 to 125
HS1-5104ARH/PROTO HS1-5104ARH/PROTO
Pinouts
HS-5104ARH (SBDIP) CDIP2-T14
TOP VIEW
OUT 1
-IN1
+IN1
V+
+IN2
-IN2
OUT 2
1
2
3
4
5
6
7
14
13
12
11
10
9
8
OUT 4
-IN4
+IN4
V-
+IN3
-IN3
OUT 3
OUT 1
-IN1
HS-5104ARH (FLATPACK) CDFP3-F14
TOP VIEW
1
2
3
4
5
6
7
14
13
12
11
10
9
8
OUT 4
-IN4
+IN4
V-
+IN3
-IN3
OUT 3
d,
L,
+IN1
V+
+IN2
-IN2
OUT 2
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
