HS-302RH-T
Data Sheet
July 1999
File Number
4603.1
Radiation Hardened
CMOS Dual DPST Analog Switch
Intersil鈥檚 Satellite Applications
(SAF) devices are fully
tested and guaranteed to 100kRAD Total Dose. These QML
Class T devices are processed to a standard 鏗俹w intended
to meet the cost and shorter lead-time needs of large
volume satellite manufacturers, while maintaining a high
level of reliability.
The HS-302RH-T analog switch is a monolithic device
fabricated using Radiation Hardened CMOS technology and
the Intersil dielectric isolation process for latch-up free
operation. Improved total dose hardness is obtained by
layout (thin oxide tabs extending to a channel stop) and
processing (hardened gate oxide). These switches offer low-
resistance switching performance for analog voltages up to
the supply rails. 鈥淥N鈥?resistance is low and stays reasonably
constant over the full range of operating voltage and current.
鈥淥N鈥?resistance also stays reasonably constant when
exposed to radiation, being typically 30鈩?pre-rad and 35鈩?/div>
post 100kRAD(Si). This device provide break-before-make
switching.
Flow
TM
Features
鈥?QML Class T, Per MIL-PRF-38535
鈥?Radiation Performance
- Gamma Dose (緯) 1 x 10
5
RAD(Si)
鈥?No Latch-Up, Dielectrically Isolated Device Islands
鈥?Pin for Pin Compatible with Intersil HI-302 Series Analog
Switches
鈥?Analog Signal Range 15V
鈥?Low Leakage . . . . . . . . . . . . . . . . 100nA (Max, Post Rad)
鈥?Low R
ON
. . . . . . . . . . . . . . . . . . . . . 60鈩?(Max, Post Rad)
鈥?Low Operating Power . . . . . . . . . . 100碌A(chǔ) (Max, Post Rad)
Pinouts
HS1-302RH-T (SBDIP), CDIP2-T14
TOP VIEW
NC 1
S3 2
D3 3
D1 4
S1 5
IN1 6
GND 7
14 V+
13 S4
12 D4
11 D2
10 S2
9 IN2
8 V-
Speci鏗乧ations
Speci鏗乧ations for Rad Hard QML devices are controlled by
the Defense Supply Center in Columbus (DSCC). The SMD
numbers listed below must be used when ordering.
Detailed Electrical Speci鏗乧ations for the HS-302RH-T
are contained in SMD 5962-95812.
A 鈥渉ot-link鈥?is provided
from our website for downloading.
www.intersil.com/spacedefense/newsafclasst.asp
Intersil鈥檚 Quality Management Plan (QM Plan), listing all
Class T screening operations, is also available on our
website.
www.intersil.com/spacedefense/newsafclasst.asp
HS9-302RH-T (FLATPACK), CDFP3-F14
TOP VIEW
1
NC
S3
D3
D1
S1
IN1
GND
2
3
4
5
6
7
14
13
12
11
10
9
8
V+
S4
D4
D2
S2
IN2
V-
Ordering Information
ORDERING
NUMBER
5962R9581201TCC
5962R9581201TXC
PART
NUMBER
HS1-302RH-T
HS9-302RH-T
TEMP.
RANGE
(
o
C)
-55 to 125
-55 to 125
Functional Diagram
N
P
D
IN
NOTE:
Minimum order quantity for -T is 150 units through
distribution, or 450 units direct.
TRUTH TABLE
LOGIC
0
1
ALL SWITCHES
OFF
ON
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
www.intersil.com or 407-727-9207
|
Copyright
漏
Intersil Corporation 1999
Satellite Applications Flow鈩?(SAF) is a trademark of Intersil Corporation.
