CRYSTAL CLOCK OSCILLATORS
ECL
Data Sheet 9205C
Rev. J
HS-2800/2810 Series
Description
The
HS-2800/2810 Series
of quartz crystal oscillators provide MECL 10K and 10KH series compatible
signals in industry standard four-pin DIP hermetic packages. Systems designers may now specify space-
saving, cost-effective packaged ECL oscillators to meet their timing requirements.
Features
鈥?Wide frequency range鈥?0.0MHz to 250.0MHz
鈥?User specified tolerance available
鈥?Will withstand vapor phase temperatures of 253擄C
for 4 minutes maximum
鈥?Space-saving alternative to discrete component
oscillators
鈥?High shock resistance, to 3000g
鈥?Metal lid electrically connected to ground to
reduce EMI
Electrical Connection
HS-2800
Pin
Connection
1
7
8
14
Output Complement
V
CC
Ground
Output
V
EE
-5.2V
鈥?Low Jitter
鈥?MECL 10K and 10KH series compatible output on
Pin 8, complement on Pin 1
鈥?High Q Crystal actively tuned oscillator circuit
鈥?Power supply decoupling internal
鈥?No internal PLL avoids cascading PLL problems
鈥?High frequencies due to proprietary design
鈥?Gold plated leads - Solder dipped leads available
upon request
HS-2810
Pin
Connection
1
7
8
14
Output Complement
V
EE
-5.2V
Output
V
CC
Ground
Dimensions in inches and (MM)
