HS-1115RH
Radiation Hardened, High Speed, Low Power
Output Limiting, Closed-Loop-Buffer Amplifier
Description
The HS-1115RH is a radiation hardened, high speed closed
loop buffer featuring both user programmable gain and out-
put limiting. They are QML approved and processed in full
compliance with MIL-PRF-38535. Manufactured in propri-
etary, complementary bipolar UHF-1 (DI bonded wafer) pro-
cess, the HS-1115RH also offers a wide -3dB bandwidth of
225MHz, very fast slew rate, excellent gain flatness and high
output current.
This buffer is the ideal choice for high frequency applications
requiring output limiting, especially those needing ultra fast
overload recovery times. The limiting function allows the
designer to set the maximum positive and negative output
levels, thereby protecting later stages from damage or input
saturation. The HS-1115RH also allows for voltage gains of
+2, +1, and -1, without the use of external resistors. Gain
selection is accomplished via connections to the inputs, as
described in the 鈥淎pplication Information鈥?text. The result is a
more flexible product, fewer part types in inventory, and
more efficient use of board space.
Compatibility with existing op amp pinouts provides flexibility to
upgrade low gain amplifiers, while decreasing component
count. Unlike most buffers, the standard pinout provides an
upgrade path should a higher closed loop gain be needed at a
future date.
Detailed electrical specifications are contained in SMD
5962F9678501VPA, available on the Intersil Website.
A
Cross Reference Table
is available on the Intersil Website
for conversion of Intersil Part Numbers to SMDs. The address is:
www.intersil.com/military/crossref.asp
SMD numbers must be used to order Radiation Hardened
Products.
August 1996
Features
鈥?Electrically Screened to SMD 5962F9678501VPA
鈥?MIL-PRF-38535 Class V Compliant
鈥?User Programmable Output Voltage Limiting
鈥?User Programmable For Closed-Loop Gains of +1, -1
or +2 Without Use of External Resistors
鈥?Standard Operational Amplifier Pinout
鈥?Fast Overdrive Recovery . . . . . . . . . . . . . . . <1ns (Typ)
鈥?Low Supply Current. . . . . . . . . . . . . . . . . . 6.9mA (Typ)
鈥?Excellent Gain Accuracy . . . . . . . . . . . . . . 0.99V/V (Typ)
鈥?Wide -3dB Bandwidth . . . . . . . . . . . . . . . 225MHz (Typ)
鈥?Fast Slew Rate . . . . . . . . . . . . . . . . . . . . 1135V/渭s (Typ)
鈥?High Input Impedance . . . . . . . . . . . . . . . . . . 1M惟 (Typ)
鈥?Excellent Gain Flatness (to 50MHz) . . . . .
鹵0.1dB
(Typ)
鈥?Total Gamma Dose . . . . . . . . . . . . . . . . . 300K RAD (Si)
鈥?Neutron Damage . . . . . . . TBD (When Tests Complete)
鈥?Latch Up . . . . . . . . . . . . . . . . . . . None (DI Technology)
Applications
鈥?Flash A/D Driver
鈥?Video Switching and Routing
鈥?Pulse and Video Amplifiers
鈥?Wideband Amplifiers
鈥?RF/IF Signal Processing
鈥?Imaging Systems
Ordering Information
PART NUMBER
5962F9678501VPA
HFA1115IP
(Sample)
HFA11XXEVAL
TEMP.
RANGE (
o
C)
-55 to 125
-40 to 85
PACKAGE
8 Ld CERDIP
8 Ld PDIP
PKG. NO.
GDIP1-T8
E8.3
Evaluation Board
Pinout
HS-1115RH
MIL-STD-1835, GDIP1-T8
(PDIP, CERDIP)
TOP VIEW
NC
-IN
+IN
V-
1
2
3
4
350
+
350
8
7
6
5
V
H
V+
OUT
V
L
-
